Beer Can Filling Machine/Aluminum Can Filling Production Machine /Beer Canning Line SHTGF20 4/10 2

Product Overview

Description

Welcome to>>Hangzhou Youngsun Intelligent Equipment Co., Ltd.



Beer Can Filling Machine Features:

At present, craft beer has become popular in the market. For this reason, we have developed the SHTGF20-4/10-2 can filling and capping machine, which is suitable for cans filling with gas or non-gas beverages and beer. It is a meticulously developed product for different can-type products, which has taken a solid step for our company to expand the international market.



Main parameter:

Items	Description	Techinical Spcitication
Capacity	200 cans/minute(20-4)/100 cans/minute(10-2)	330ml
	180Tank/minute	500ml
Machine efficciency	≥100%
Cans types changing time	about 30 minutes
Cans in/out direction	360°
Filling valve	20pcs(20-4)/10pcs(10-2)
Filling temperature	2-4°C
C02 content	5g/L
Filling pressure(C02)	0. 15~0. 4Mpa



Filler Characteristic SHTGF20-4/10-2:

Filling method	Isobar filling
Filling valve diameter	1000
Pitch of filing valve	163.36mm/326.72mm
Height of can transport	1250-1400mm
Filling pricision	±2.0mm
Oxygen picku	≤20ppb
Bearing brand	SKF dan NSK
Bag filter	Included(2 bags)	ss
Seam parts brand	Sealtech	Germany
Pneumatic Components	FESTO/SMC
Lubrication system	Centralized lubricatio
Dimension (LxWxH)	1700X1650 X 2350mn
Cans types	330ml, 500ml
Can height	85mm—168mm
Machine weight	3500 KG/3300KG



 Capper Characteristic SHTGF 20-4/10-2 :

Seaming head	4 heads /2 heads	6000CPM Capacity
Cap size	59.52±0.25
Can diameter	66
Material of cap roller	9Cr18Mov
Using time of cap roller	≥100/50 million cans
Materral of cap head	9Cr18
Usingle time of capping head	≥40/20 million cans
Sealing loss	≤0.05%
Cap loss	≤0.03%
Bearing brand	SKF,NSK	Sweden
Seam parts brand	Sealtch	German
Pneumatic Components	FESTO/SMC
Cap storage	1500
Compressed loss	0.2Nm3h/0.1Nm3h(0.4-0.5Mpa)
CO2 loss	3Nm3h(200CPM)/2Nm3h(100CPM)



 Electric:

Total power(KW):2.2	Frequency converter:DANFOSS	Workingvoltage:AC 380v
Motor brand:Siemens/ABB	HML:Siemens	Control electric box:ss
PLC:S7-200	Controlvoltage:DC 24v
