Biodegradable corn starch full servo thermforming machine
Major Construction Features:
Automatic corn starch Cup Making Machine is new servo equipment, which has been developed and research with several years of machine producing experiences of our company, it uses stable servo system and pneumatic technology to control together, its operation is stable, noise is small, mold locking ability is strong and quality is high. It mainly consists of formed machine, material rack, material receiving machine and screen controlled by electricity.
1. The machine is completely automatic, productive speed is fast. Different products can be produced with different molds.
2. It uses import famous brands of electric and pneumatic fittings, so the operation is stable, quality is reliable and life is long.
3. The design of the mold is advanced and special, heat the thermoplastic plastic flake board and put on the mold, pull the piston, give the pressure to the air, keep the flake board close to the inside of the mold to form, then, cut and automatically blow the product. The structure of the whole machine is compact, one mold has all the functions, like pressure giving, forming, cutting, cooling, and finished product blowing, so the process is short, quality of the finished product is high and matches with national sanitary standard.
Main technical parameter: HTL-760
Sheet material
PP.PS.PE.PET
Sheet width
720mm
Sheet thickness
0.3-2mm
Max.Forming Area
720*360
Max.Forming depth
160 mm
Forming Pressure
0.5-0.8MPA
Productivivty
10-20time/min
Heating Power
55KW
Motor Power
35KW
Total Weight
6T
Water Temperature
>30 degree
Machine dimension
6.8*2*2.2M
