Chicken farm automatic poultry feeder for floor type broiler raising
1. Automatic poultry feeder Configuration: It is composed of feed tower, feed pipe, auger motor and material level sensor. Its main function is to feed the material in the feed tower to the hopper of the auxiliary feed line, and the material level sensor to automatically control the opening and closing of the motor transmission to achieve the purpose of automatic feeding.
Feed tower( the silo)
This Acooridng to your chicken number and feed storage date, we will provide the suitable capacity silo. Feed will be transported this from the augur to feed line. --If you need , we could provide a elevator, this could directly send the feed to the silo. wil save more labo
Feed hopper
Feed will be add here, and then be transported from here to feed line.
2.Automatic Feeding Line Distribution System Configuration: It is composed of hopper, feeding pipe, auger, tray, suspension lifting device, motor and material level sensor. Its main function is to feed the material in the hopper to each tray to ensure the consumption of broilers, and the level sensor is used to automatically control the opening and closing of the motor to achieve the purpose of automatic feeding.
--Features of broiler feeding system
1. High degree of automation Using the latest high-quality national standard material level sensing system, a high degree of automation. Automatic control of feeding can be achieved. Simply check after setting.
2. Timed quantitative feeding The equipment is divided into 6-8 speeds, which can be adjusted with the growth and development of chickens, so that the feeding becomes more reasonable and scientific, and the feeding cost is reduced.
3 large capacity The trays were injection molded with 16 grids of raw materials, and each tray was calculated on 16 grids, allowing 50-70 chickens to eat at the same time.
4. Low maintenance costs The material used in the production of trays is engineering plastics, featuring high strength, non-toxicity, long service life, low maintenance cost, and a price of about 20 yuan per tray.
5. Save on farming costs Automatic control of material accuracy, uniform distribution of each tray, to solve the problem of artificial materials feeding control problems. It can also effectively reduce and reduce the workforce.
3. Chicken automatic water line Equipment configuration: filter, water meter, pressure reducer, head-end water level indicator, tail water level display tube and exhaust device, pvc water delivery tube, drinking fountain, hanging cup, fishing line, lifting device.
