0.1mm flexible copper busbar customized copper foil bus bar

Product Overview

Description

Copper foil soft conductor

Pressure welding soft connector



The pressure welding is to press the copper foil laminations together, using molecular diffusion welding, and forming by high-current heating and pressure welding.

Copper foil: 0.03mm to 0.3mm thick.
The contact surface can be tinned or silver plated according to users’ requirements.

Description of pressure welding / brazing

In order to ensure the flatness of the contact surface,
When A is greater than 90mm and B is greater than 60mm; use the contact surface paste copper friend (1mm thick) pressure welding process, see the scheme (I) shown in the figure.
When A is greater than 140mm and B is greater than 130mm: Brazing process is used, see the scheme (II) shown in the figure.

Technical parameters



See the table below.
The width, length and drilling holes not included in the table below can be processed according to user requirements.
The allowable current carrying capacity is a reference value. This value is related to the installation and use conditions of the soft connector.

Scheme (II)
Technical parameter table of pressure welding / brazing
