Product Overview

Description


8 inch open frame LCD monitor touch screen optional VGA DVI inputs 1000 nits to 1500 nits touch screen usb monitor

Product Description

ITD 8” ITD08OFT1HRC1 open frame touch monitor with front cover to protect touch sensor provides industrial or commercial users with crystal clear picture quality. The all metal enclosure is rugged in design and fit perfectly into any enclosure. It is space saving for your compact environment cabinet.



Features



 High contrast color TFT LCD display supports resolution up to 1024 x 768

Supports DDC 1/2B for Plug & Play compatibility

Advanced OSD control for picture quality adjustment

All steel construction designed for harsh and industrial environments

Easy-to-install console with open frame style

75/100mm VESA mount and side brackets

CE, FCC, RoHS Compliance



Optional

AR/AG Tempered glass

Sunlight Readable, light sensor

Touch sensor technologies: resistive, PCAP

Video Signal input: AV, S-Video

Specification

Panel

Cell Type/Glass Surface

TFT

Aspect Ratio/Size

8” 4:3

Active Area/Pixel Pitch

162(W)×121.5 (H)/0.2025(H)×0.2025(V)mm

Native Resolution/Colors

1024 x 768 /16.7M

Brightness/Contrast

250nits/500:1

Response Time

10ms

Viewing Angle(Typical)

140(H)/120(V)

Light Source

LED Backlight with 50000Hours’Lifetime

Input Signals

VGA, HDMI

Convenient Features

Backlight adjustment, Plug & Play, OSD Multi-Languages

Power

External AC-to-12VDC power adapter with universal/Auto-Sensing

Power Consumption

Operation/Power Saving

Below 10W

Touch Panel

Resistive Touch Screen

Touch Interface

USB or RS232

Key Control

Power on/off with LED, Menu, Select, Adjustment(Right/Left)

Order Information

8”XGA open frame monitor no touch/ITD08OFN1HRC1

8”XGA open frame monitor with PCT/ITD08OFT5HRC1

8”XGA open frame monitor with tempered glass/ITD08OFG1HRC1





Product Display






Packaging & Shipping


Firm, safe, standard cartons with foams

Wooden Shelf or BOX for big sizes and big quantiity





Our Services

All ITD products come standard with a 2-year comprehensive warranty. Additionally, our extended warranty service, offered up to 3 years, provide extra peace of mind that any problem will be solved quickly and effectively. ITD also offers tailored service contracts to meet our partners’ specific needs.
With service and support centers in Hong Kong, China mainland, Europe, we are able to respond quickly and efficiently to ensure uninterrupted productivity for our customers. We are committed to speedy turnaround times on repairs and service needs.

- DOA Service (Dead On Arrival):
To run DOA within 1 month after shipment. Goods are guaranteed to exchange when it is returned.
New product operation would be completed within 5-20 working days. Round trip shipping costs are paid by ITD. The following failures are allowed to be serviced by DOA:
A: The image cannot display normally.
B: It cannot be powered on.
C: The internal functions of monitors are out of work.

- RMA Service (Return Merchandise Authorization):
To run RMA within 24 months after shipment (TFT LCD panels come with 12months' warranty). Maintenance time lasts from 5 to 20 working days according to the difficulty and specific situation. Returning shipping cost after maintenance is paid by ITD.



Company Information

 ITD is a worldwide leading industrial touch display equipment’s solutions provider with an after-service center in Netherlands combining researching, developing, manufacturing, marketing & service with an excellence in varied kinds of industrial displays and touchscreen products started from 2005 and later expanded to embedded panel PC, digital signage, rugged stainless steel/aluminum alloy IP65 industrial displays, and ultra-wide stretched bar LCD displays for industries ranging from banking, transportation and logistics, to automation, marine, railway, oil and gas, energy, healthcare, and field service.
