5mm oval LED yellow diffused Diode led

Share on (60864113642):


Price:RUB 1.54

Quantity:


Product Overview

Description

Product Information
 5mm oval LED yellow diffused Diode led


Lamp Type LED chip Chip Material AlGaAs
Model Number WEJ564YD-AS3 Emitted Color yellow

Viewing Angle

 110°  Resin color yellow diffused
 Forward Current   30mA  Power dissipation   120mW
 Reverse Voltage  5.0V  Peak Forward Current  100mA
 Operating Temperature  -25~+85℃  Electro-Static-Discharge 2000V
 Lead Solder Temperature  260℃ Storage Temperature  -40~+100℃
Features High brightness;Low power consumption;High reliability and stability.
Flexibility in optical design and mechanical design.
Applications Optical indicator;Indoor lighting;Interior automotive lighting;Backlight for LCD,switch and Symbol,display;Light pipe application;Advertisement

  paste-pic-dp_uuid_agec9

Why choose us?


Fair&Certification


Related Products


                              IR & PD & PT                                                           DIP LED                                                              Lamp LED Holder


                                SMD LED                                                                Chip LED                                                             Bridge Rectifiers


                    Diodes & Transistors                                                    LED Spotlight                                                       LED Night Light



Payment&Shipping
5mm  Round Straw Hat led




FAQ


1. What will be the best price terms?

We can accept FOB, EXW, CIF normally and other terms according to customers special requirement.



2.How long does it take to customize a sample?

We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize



3. Could you please send me the sample for the same . So that i could see and analyze its quality?

Yes. We can send samples first, samples need to be charged if the value is higher



4.How soon will my order shipped?

Generally, upon the receipt of payment, goods will be shipped out within 2 working days for samples. (Note: Exact delivery time mainly depends on the carrier services.



5.How much will the express delivery cost?

The shipping discount are different because of different weight, volume and destination, we will choose the cheapest and safest way according to your detailed requirement. For the exact cost, please contact us freely.



6.How to choose LED light source ?

Lumens(LM), light efficency(LM/W), life span((hrs) are very important factors when choosing LED light source. The higher, the better. Besides, brand of LED chip, LED base and other materials will influence the product reliability.



7.What’s your Delivery Time?

In generally , the delivery time :3-5days.



8.How do I track my shipment?

We ship your purchase before the end of the next business day after you have checked-out. We would send email with tracking number, so you can check the progress of your delivery at the carrier’s website.
