2 Way Power tapper 694-2700MHz N female connector

Description.

RF power taps are designed for use in applications of indoor antenna and radiating cable systems. These broadband power taps feature low insertion loss and excellent impedance match. Careful and conservative mechanical designs assure a long service life with high reliability and stability.

         _____________________________________   TECHNICAL SPECIFICATIONS   ______________________________________

\t
Frequency (MHz)
\t
694-2700
\t
Application
\t
Indoor or Outdoor
\t
Impedance (Ω)
\t
50
\t
Temperature Range
\t
-35℃ to +75℃
\t
PIM
\t
≤-150dBC@2*43dBm
\t
Housing Material
\t
Aluminum
\t
IP Grade
\t
IP65
\t
Color
\t
Black
\t
Part No.
\t
Couple (dB)
\t
Output Split
\t
Ratio
\t
VSWR
\t
Insert Loss (dB)
\t
Power (W)
\t
Humidity
\t
Connector
\t
PT-F1-3NF-150
\t
3
\t
-1.8/-4.8
\t
2:1
\t
1.35:1
\t
-1.8±0.8
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-5NF-150
\t
4.8
\t
-1.3/-6.1
\t
3:1
\t
1.35:1
\t
-1.3±0.8
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-6NF-150
\t
6
\t
-1.0/-7.0
\t
4:1
\t
1.35:1
\t
-1.0±0.8
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-7NF-150
\t
7
\t
-1.0/-7.8
\t
4:1
\t
1.35:1
\t
-1.0±0.8
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-8NF-150
\t
8
\t
-0.7/-8.5
\t
6:1
\t
1.35:1
\t
-0.7±0.8
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-10NF-150
\t
10
\t
-0.4/-10.5
\t
10:1
\t
1.3:1
\t
-0.4±1.0
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-13NF-150
\t
13
\t
-0.2/-13.0
\t
20:1
\t
1.3:1
\t
-0.2±1.2
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-15NF-150
\t
15
\t
-0.1/-15.3
\t
30:1
\t
1.3:1
\t
-0.1±1.25
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-20NF-150
\t
20
\t
-0.1/-20.1
\t
100:1
\t
1.3:1
\t
-0.1±1.5
\t
100
\t
5-95%
\t
N Female
\t
PT-F1-30NF-150
\t
30
\t
-0.1/-30.1
\t
1000:1
\t
1.3:1
\t
-0.1±2.0
\t
100
\t
5-95%
\t
N Female
