Factory Sell 280w Poly Solar Panel Applied Off Grid Solar Power System China CE 3 Years,3 Years 0 to 5W 5400 Pascals 30V 18.5kg
- Category: >>>
- Supplier: Longt Lighting Group INC.
Share on (60872158416):
Product Overview
Description
High efficiency 85w solar panel cells factory
Product Description
| 255W-265W POLY PANEL ELECTRICAL CHARACTERISTICS | |||
| Minimum performance at stc1 | |||
| Item | 255W | 260W | 265W |
| Cell Type | Poly | Poly | Poly |
| Model No. | MJ-P-60-PID | MJ-P-60-PID | MJ-P-60-PID |
| Maximum Power(Wp) | 255 | 260 | 265 |
| Maximum Power Voltage(V) | 30.5 | 30.6 | 30.8 |
| Maximum Power Current(A) | 8.37 | 8.5 | 8.61 |
| Open Circuit Voltage(V) | 38.1 | 38.2 | 38.3 |
| Short Circuit Current(A) | 8.88 | 9 | 9.1 |
| Solar Panel Efficiency | 15.60% | 15.9% | 16.2% |
| Power Tolerance | ±5% | ±5% | ±5% |
| Standard Test Condition | Irradiance 1000W/M2, Cell Temperature 25ºC, Air Mass 1.5 | ||
| TEMPERATURE CHARACTERISTICS | |||
| NOCT(Nominal Operating Cell Temperature) | 44°C (±2°C) | ||
| Temperature Coefficient of Pmax | -0.41%/°C | ||
| Temperature Coefficient of Voc | -0.34%/°C | ||
| Temperature Coefficient of Lsc | +0.05%/°C | ||
| Maximum Systerm Voltage | 1000 DC | ||
| Max Series Fuse Rating | 15A | ||
| Operating Temperature | -40ºC~+85ºC | ||
| MECHANICAL PARAMETERS | |||
| Number of Cells(Pcs) | 60(6x10) | ||
| Frame | Anodized Aluminium Alloy | ||
| Dimension(mm) | 1650x992x35mm | ||
| Cell Size(mm) | 156x166mm | ||
| Glass | 3.2mm, High Transmission, Low Iron, Tempered Glass | ||
| Junction Box | IP65&IP70 | ||
| Output cable | TUV, 4mm² , 1000mm | ||
| Connector | MC4 Compatible | ||
| Weight(kg) | 18.6 | ||
| Warranty | 10 year product warranty,25 year linear power guarantee | ||
| PACKING CONFIGURATION | |||
| Container: | 20GP | 40GP | 40HC |
| Pieces per container: | 372 | 840 | 892 |
Solar panel
Advantage:
High efficiency and transmission rate, low iron tempered glass,Manufacturing with IEC61215 standard
Types of solar panel:
Mono crystalline silicon & Poly crystalline silicon.
The features
The high efficiency solar PV module adopts the world’s highest efficiency cell with efficiency up to 23%, and efficiency of the module is 25-30% higher than the traditional ones, this cell’s positive pole and the negative pole are on the same side, the cell’s front side can absorb maximum sunlight, so that it can get the maximum power.
Advantages
* The above configuration is only for reference and the actual configuration is designed according to the local climate conditions and the customer special requirements.
* We promise a guaranteed warranty for the entire system for three years, during which if there is any quality problem found, repair or replacement shall be provided free of charge, and a guarantee for life-long repair.
