DS-120 Open Area Dust Control Sprayer System Fog cannon
The Fenghua® is an innovative product patented by Fenghua Environment Protection Machinery Co., Ltd a company that is well established in the environment field. It has been designed to tackle the problem of airborne particles and dust generated by open mining activities, materials handling, waste disposal odors, demolition, stock piles, port facilities, construction and many other applications.
The Fenghua® suppresses up to 90% of airborne dust particles.
The Fenghua®, which is available as a manual and fully automated version, covers the needs of all possible working activities:
• Suppresses dust in open air (quarries, job-sites, squares, etc.);
• Suppresses dust concentrations (loading/unloading trucks, transfer by conveyor belt, unloading hoppers, etc.).
Features:
1 Flexible installation:fixed on the concrete platform or diesel generator-powered vehicles available
2 Flexible power: three-phase 380V and diesel generator power supply available
3 Remote control & manual control operation available
4 Compare to tank car, water consumption save 70% ~ 80%, wide coverage area.
Applicance
• Quarries and mines
• Cement factories and steel mills
• Demolition
• Crushing machines
• Storage and handling of bulk materials
• Parks carbon storage;
• Discharge hoppers;
• Points of loading and unloading ships;
• Points fall in conveyor belts or transfer of material
Main Technical Parameters
TYPE
DS-120
Certificate
CE/CCC/ISO9001:2008
Throw
≥120m
Volume Flow
150L-200L/min
Fog Droplet Size(adjustable )
50-300μm
Water Pressure(Mpa)
2.5-3.5Mpa
Motor/rpm
2900
Horizontal Rotation Angle(adjustable )
320°
Pitching Angle(adjustable )
-10°~40°
Coverage Area
32153.6m2
Total Power
97KW(75+22)
Product Size(L*W*H)
2950*1540*2750mm
Net Weight
1200kg
Fan Volume
4000m3/min
Fan Pressure
1200Pa
Warranty
1year
MOQ
1
Payment
Deposit received by T/T; L/C at sight, ect
Certification
Worksite Photos
Production Flow
Packaging
1. Outside package: standard export plywood case
2. Inner package: air bubble& stretch film and screwed to the pallet.
3. Different design need different shipping way: LCL or FCL.
1,We are manufacturer with own factories and R&D Dept. We have more than 20 years of experience on exporting dust suppression sprayer system and pest control sprayer. Good technology support will be very helpfull in our cooperation.
2.The material we choose is always the environmentally friendly ones and products always come out with good quality.
3,We also provide many kinds dust suppression system solutions for customer choose.
4,A trial order or sample orders are accepted.
5,We have a stable and professional service team with more than 5 years of experience,export to Europe,North America,Middle east and so on.
6.We support you with good service,payment terms,lead time and logistics control.
7,Warranty: Our company always provide after-sales-service for 12 months,if goods arrival with faulty or damage,we would like to provide spare parts for free.
8, We are seeking global distributors. Please come to us to get more information.
