Монокристаллическая солнечная панель для домашнего использования, 200 Вт, 250 Вт, 300 Вт, моно, Лучшая цена
- Category: Solar Panels >>>
- Supplier: Foshan Tanfon Energy Technology Co. Ltd.
Share on (610450409):
Product Overview
Description
Product Description
1. IP68 Junction Box, Connector
2. 15A current
3. Super strong frame
4. Current division
5. Salt spray, Ammonia and PID test
6. Strong Mechanical load capacity
7. Color Classification
2. 15A current
3. Super strong frame
4. Current division
5. Salt spray, Ammonia and PID test
6. Strong Mechanical load capacity
7. Color Classification
Moduel | FSM300W | FSM320W | FSM330W | FSM340W | FSM350W | FSM360W | |||||
Rated Maximum Power at STC | 300W | 320W | 330W | 340W | 350W | 360W | |||||
Open Circuit Voltage(Voc/V) | 46V | 46.1V | 46.34V | 46.5V | 47.13V | 47.13V | |||||
Maximum Power Voltage(Vmp/V) | 38.7V | 38.8V | 37.57V | 38.2V | 39.3V | 38.39V | |||||
Short Circuit Current(Isc/A) | 9.53A | 9.65A | 9.75A | 9.25A | 9.35A | 9.45A | |||||
Maximum Power Current(Imp/A) | 9.04A | 9.15A | 8.78A | 9.21A | 9.25A | 9.37A | |||||
Module Efficiency(%) | 20.13% | 20.39% | 20.65% | 20.91% | 21.17% | 21.43% | |||||
Power Tolerance | 0 ~ +3% | ||||||||||
Standard Test Condition(STC) | 1000W/m2 irradiance, 25°C cell temperature, AM1.5 | ||||||||||
MECHANICAL SPECIFICATION | ||
Cell Type | Mono Crystalline 156.75x156.75mm | |
Number Of Cells | 72（6x12） | |
Dimensions(A*B*C) | 1950x990x40mm | |
Weights | 23KG | |
Front Glass | 3.2mm Tempered Low Iron Glass | |
Frame | Clear Anodized Aluminum Alloy | |
Junction Box | IP68,with Bypass Diodes | |
Connector | Mc4 Compatible | |
Output Cables | TUV,±length 900mm,4.0mm² | |
Details
Production Process
Packing & Delivery
PACKING CONFIGURATION | ||||
Container | 20’GP | 40’GP | ||
Pieces Per Pallet | 27 | 27 | ||
Pallets Per Container | 10 | 24 | ||
Pieces Per Container | 270 | 648 | ||
By Sea | Delivery from Foshan or Guangzhou seaport | ||||
By Express | DHL | ||||
Solar Projects
Tanfon Solar Case
Products have been sold to more than 130 countries, Importantly, we have one professional installation team, has been to 32 countries and regions for installation service as well as win good feedback from the customers.
About Tanfon
Why Choose Tanfon
100% Order Safe
One-stop Service
We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours.
For more information, please send an inquiry or contact us directly.
