WD615.67C steyr marine engine 164KW to 180KW

Product Overview

Description

WD615.67C steyr marine engine 164KW to 180KW

WD615 series marine diesel engine

TypeWater cooled, inline, 4-stroke, dry cylinder liner, direct injection, turbocharged, turbocharged inter-cooled

Num of cylinders6

Bore/Stroke(mm)126/130

Fuel consumption(g/kW.h)≤198

Oil/fuel consumption(g/kW.h)≤0.5

Stable governing rate(%)≤8(mechanical)

Starting methodElectrical starting

Idle speed(r/min)650±50

Smoke(Rb)≤1.2

Displacement(L)9.726

(dB(A)) Noise≤108

EmissionEuroI Euro II

Crankshaft rotation directioncounter clockwise(face to flywheel end)





Type	No. of cylinder	Bore/stroke (mm)	Displacement (L)	Rated output (kW)	Rated speed (r/min)
WD615.61C	6	126/130	9.726	140	1800
WD615.67C	6	126/130	9.726	176	1800
WD615.68C	6	126/130	9.726	205	2100
WD615.46C	6	126/130	9.726	220	2100
WD615C-21	6	126/130	9.726	190	1500
WD615C-22	6	126/130	9.726	176	1500
WD615C-23	6	126/130	9.726	160	1500
WD615C-24	6	126/130	9.726	140	1500
WD615.61C-2	6	126/130	9.726	147	2100
WD615.61C-6	6	126/130	9.726	110	1800
WD615.67C-15A	6	126/130	9.726	136	1500
WD615.67C-20	6	126/130	9.726	180	2000
WD615.61C-2A	6	126/130	9.726	121	2100
WD615.61C-10A	6	126/130	9.726	110	1800
WD615.68C-18	6	126/130	9.726	160	1800
WD615.68C-2	6	126/130	9.726	190	1800
WD615.68C-19	6	126/130	9.726	192	1900
WD615.61C-15	6	126/130	9.726	110	1500







Model	Order No.	Cyl No. Bore Stroke	Rated Power/Speed	Overload Power/Speed	LxWxH Dimensions	Weight	Adaptable Gearbox Type
		mm	kW/r/min	kW/r/min	(mm)	kg
WD615.61C	61561C01N	6x126x130	110/1800	121/1858	1492x830x1170	850	135 120C MB242 MB270A 300
	61561C02N		140/1800	154/1858
	61561C03N		110/1500	121/1545
	61561C04N		120/1500	132/1545
	61561C05N		155/2000	170.5/2060
WD615.64C	61564C01N	6x126x130	147/1500	162/1545	1492x830x1170	850	135 120C MB242 MB270A 300
	61564C02N		158/1800	174/1858
	61564C03N		147/1800	162/1858
WD615.67C	61567C01N	6x126x130	176/1800	194/1858	1912x830x1170	850	135 120C MB242 MB270A 300
	61567C02N		180/2000	198/2060			135 MB242 MB270A 300 D300A
	61567C03N		164/1500	180/1545			135 MB242 MB270A 300
WD615.68C	61568C01N	6x126x130	200/1800	220/1858	1912x830x1170	900	135 MB270A 300 D300A 120C
	61568C02N		205/2100	226/2163
	61568C03N		180/1500	198/1545
WD615.46C	61546C01N	6x126x130	240/2100	264/2163	1912x830x1170	900	MB270A 300 D300A HC120C
	61546C02N		230/1800	253/1858
	61546C03N		202/1500	222/1500
WD615.57C	61557C01	6x126x130	257/2000	283/2060	1960x830x1170	950	MB270A 300 HC200 D300A
