precast hollow core slab machine for prefab house GLY 200x1200
008615866626003
Product Description
1.Introduction of Hollow core slab machine
Haitian is a professional producer of pre-stressing concrete hollow core slab forming machine. It characters as bellow: suitable design, easy for operation and maintenance, durable spare parts etc. With smooth surface, solid construction, high strength and precise dimension, the hollow core slab meets all the national specification requirements.
It became the best and economical choice for factory produce high strength hollow core slab for workshop, school, hospital, shopping mall, office building, warehouse and residence.
2. Specification of Concrete Hollow core slab machine:
No.
Model
Size of Slab (mm)
Power (kw)
Weight / meter (kg)
No. of Steel Strands, Steel Rope Ø, Span in Meter, & Max. Load Carring Capacity kN/m2
1
TW
120-600
Thickness - 120 Width - 600
8.5
100
8 Nos.
5 mm
4.5 mtr
4.6 kN/m2
6 Nos.
7 mm
4.5 mtr
6.54 kN/m2
6 Nos.
7 mm
6 mtr
2.27 kN/m2
2
TW 150-600
Thickness - 150 Width - 600
10.5
125
5 Nos.
7 mm
4.5 mtr
8.27 kN/m2
7 Nos.
7 mm
6 mtr
4.94 kN/m2
5 Nos.
9.5 mm
6 mtr
5.23 kN/m2
3
GLY 150-1200
Thickness - 150 Width - 1200
18.5
250
12 Nos.
7 mm
4.5 mtr
10.98 kN/m2
12 Nos.
7 mm
6 mtr
4.54 kN/m2
10 Nos.
9.5 mm
6 mtr
6.19 kN/m2
4
GLY 180-1200
Thickness - 180 Width - 1200
18.5
270
10 Nos.
9.5 mm
6 mtr
9.72 kN/m2
8 Nos.
12.7 mm
6 mtr
12.83 kN/m2
10 Nos.
12.7 mm
7.5 mtr
8.72 kN/m2
5
GLY 200-1200
Thickness - 200 Width - 1200
22
300
10 Nos.
9.5 mm
6 mtr
11.36 kN/m2
8 Nos.
12.7 mm
7.5 mtr
8.11 kN/m2
10 Nos.
12.7 mm
9 mtr
6.36 kN/m2
Sr. No.
Model
Size of Slab (mm)
Power (kw)
Weight / meter (kg)
No. of Steel Strands, Steel Rope Ø, Span in Meter, & Max. Load Carring Capacity kN/m2
6
GLY 250-1200
Thickness - 250 Width - 1200
33
315
8 Nos.
12.7 mm
7.5 mtr
11.15 kN/m2
10 Nos.
12.7 mm
9 mtr
9.16 kN/m2
10 Nos.
12.7 mm
10.5 mtr
5.76 kN/m2
10 Nos.
12.7 mm
12 mtr
2.86 kN/m2
7
GLY 300-1200
Thickness - 300 Width - 1200
40
380
12 Nos.
9.5 mm
7.5 mtr
11.59 kN/m2
10 Nos.
12.7 mm
9 mtr
8.63 kN/m2
10 Nos.
12.7 mm
10.5 mtr
6.60 kN/m2
12 Nos.
12.7 mm
12 mtr
5.60 kN/m2
8
GLY 380-1200
Thickness - 380 Width - 1200
39.5
480
14 Nos.
9.5 mm
9 mtr
10.20 kN/m2
10 Nos.
12.7 mm
10.5 mtr
7.64 kN/m2
10 Nos.
12.7 mm
12 mtr
5.91 kN/m2
12 Nos.
12.7 mm
13.5 mtr
4.58 kN/m2
Detailed Images
-3.Specifications of concrete Hollow core slab machine:
