A20 T20 B2 C 2 way 3/4 'DN20 мини моторизованный шаровой кран 12v

Product Overview

Description

Product Description

  A20-T20-B2-C 2 way 3/4'' DN20 mini motorized ball valve 12v
Tonhev 2 way fullport  motorized brass water ball valve, with different wire control , DC5V/DC12/VDC24V/AC100-24V valve, CE ,IP67 , meatal gears in valve actautor


Technical Parameters

Product size	NPT/BSP 3/4”
Maximum working pressure	1.0MPa
Circulation medium	Fluid, air
Rated voltage	AC/DC9-24V
Wiring control methods	CR2-02
Working current	≤500mA
Open/close time	≤5S
Life time	70000 times
Valve Body material	Brass
Actuator material	Engineering Plastics
Sealing material	FKM & PTFE
Actuator rotation	90°
Max. torque force	2 N.M
Cable Length	0.5m
Environment temperature	-15℃~50℃
Liquid temperature	2℃~90℃(Brass valve)
Manual override	No
Indicator	Yes
Protection class	IP67
Certificate	CE(LVD EMC),ROHS
Company passed	Iso9001:2015



Valve can with manual override and indicator :









Detailed information









Application

Water meter , water leak detection system and water treatment etc equipment

HAV and fire works. Automatic drain system

Irrigation ect small control equipment



Pls confirm the above different versions of actuators



When you inquiry the valve, pls confirm the detail  technical data :

1, valve size , materail

2, working voltage

3, wire control

4, valve manual override & indicator ( yes or no)

5, actuator cable length

Pre-sale service

1.We have full stock and can deliver within short time.

2.OEM and ODM order are accepted, Any kind of logo printing or design are available.

3.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

4.All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

After you choose:

1. We will count cheapest shipping cost and make invoice to you at once.

2. Check quality again, then send out to you at 1-2 working day after your payment

3. Email you the tracking no., and help to chase the parcels until it arrive you.

After-sale service

1.We are very glad that customers give us some suggestion for price and products.

2.If you have any question,please contact us freely by E-mail or Telephone.


TONHEFLOW is a manufacture in China specilized in mini motorized shut off ball valve (1/4”~2’’).And valve actuator which are approved CE certification and SS valve approved NSF61 international certification.

we buy a PICC insurance for our products in 2016. I belive they are more reliable and guaranteed for your customer or the user.
Our company also approved SGS ISO9001 in 2013 .

FAQ

Q. what is your payment term?

 A: T/T 30% down payment, balance to be paid before shipment. or L/C.

Q: what is your main market?

A: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Q: How about your products and company approved?

 A: Our products are approved CE, NSF61, Rohs, protection class IP67, Our company also approved SGS ISO9001 since 2013.

Q: Can I get samples from your factory?

A: Yes, Samples can be provided.

Q: If products have some quality problem, how would you deal with?

A: We will responsible for all the quality problems, we buy a PICC insurance for our products in 2016. I belive they are more reliable and guaranteed for your customer or the user.
