OEM 8620/20CrMnTi Helical Teeth Gears with Gear Grinding
OEM 8620/20CrMnTi Helical Teeth Gears with Gear Grinding
OEM 8620/20CrMnTi Helical Teeth Gears with Gear Grinding

OEM 8620/20CrMnTi Helical Teeth Gears with Gear Grinding

Share on (62001048432):


Price:$21.00 - $24.90

Quantity:


Product Overview

Description



Products Description


Specification
Precision grade
ISO 1328 grade 7
Number of teeth(Z)
Helix Angle(β)
15°
Pressure Angle(α）
20°
Material
SAE 4320
Heat Treatment
Carburizing
Hardness
58±2 HRC, 0.8~0.95mm deep


Catalog No.
Module
No. of teeth
Helix Direction
Pitch dia.(d)
Tip dia.(OD)
Face width(B)
Dia.(d1)
Total length(L)
Mating Gear
I0001402
2.25
20
left
46.69
51.56
49
41
116
I0001434
I0001418
2.5
17
right
44.00
49.00
36
30
241
I0005887
I0005223
2.5
19
right
49.18
54.18
45
54
281
I0005888
I0001404
3
21
left
65.22
71.31
50
35
146
I0005222
I0005220
3
21
left
65.22
71.31
50
35
175
I0005222
I0005219
3.5
19
right
68.92
76.51
68
55
380
I0003897
I0006056
3.5
21
left
72.26
83.78
54
45
205
I0003896
I0006057
3.5
21
left
72.26
83.78
54
60
164
I0005224
I0005218
4.5
21
left
97.83
106.83
65
60
262
I0003898
I0001412
4.5
21
left
97.83
106.83
92
50
262
I0003899


Thank you for reaching out to us for your custom gear requirements. Our Engineering team will review your request and will be in contact within 24 hours. - SMM TEAM | sales(@)shsmm.com


Company Profile


Shanghai Michigan Mechanical Co. Ltd - Concentrate on OEM Transmission Parts for More Than 15 Years.
Mission: Supporting the Further Success of Clients and Partners with Mechanical Solution & Premium Service.
Core Value: Customer First; Integrity; Never Stop Improving.






EQUIPMENT


Mitsubishi
Hobbing machine GE15A
Hamai
N80 Hobbing machine
Kashifuji
Hobbing machine KN80


Liebherr
LGG280 Grinding Machine
Qinchuan
YKS7225 CNC worm wheel grinder
SCHERER
Double spindle vertical type turning center VDZ 100DS


Related Products




Production Process






Testing




CNC Gear Testing TTI-150E Kingelnberg GmbH P26 Mahr UD130 Automatic Inspection Line


How Do Our Technical And Quality Team Support Our Clients And Partners ?
Our english speaking engineers do not simply relay messages. We help both customers and partners to strive for real solutions and we practise Kaizen in every single work.


Quality Warranty : 12 months counting from the delivery of the goods.


Product packaging




Inner Package Carton Non-solid Wood Packing Iron box packing


To be packed in new strong case(s)/carton(s), suitable for long distance ocean/air and inland transportation. In addition,we are willing to customize packaging per your request.


Certifications


ISO 9001 certification
ISO/TS 16949 certification


Main Application Fields


Over 15 years accumulating, SMM gears are used in various industries in numerous machines. The main application fields
including,but not limited to machine tools,UAV,Tobacco machinery,new energy automobile,electical tools,cement vertical mill,oil drilling machine.

SMM have been working with some global leading companies more than 10 years.
