Ø Description

The DVS2811 is full digital 2-phase stepper driver based on DSP control,the voltage ranges from 40V to 130VAC. It is designed for use with the 2-phase hybrid stepper motor of all kinds with 57mm to 110mm outside diameter, regulated phase current from 0.5A to 8.0A. The circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly without noise and vibration.

Ø Application

It is widely used in curving machine, processing equipment, packing machine, electronic machine, and etc.

Ø Feature

l 16 channels constant angle, constant torque micro steps, highest micro step:40000ppr

l Highest response frequency: 200Kpps

l Current of winding will be reduced by approximately 50% when no step pulse command is received for 1.5 seconds

l Opto-isolated signal I/O

l Drive current is adjustable in 16 channels from 0.5A/phase to 8.0A/phase

l Single power supply from Single power supply from 40V to 130VAC

l Better to overcome the problem of low frequency vibration

l Dimension : 178×67×108mm3;   Net Weight : 1Kg

Ø Current Setting

Stepper driver working current is set by DIP switches D1 to D4.

Ø Subdivision(micro step) Setting

The subdivision (micro step) is set by DIP switches D5 to D8, 16 channels in total. D9 and D10 are used to set the driver function.

Subdivision (micro step) ppr	200	400	800	1000	1600	2000	3200	4000
D5	ON	ON	ON	ON	ON	ON	ON	ON
D6	ON	ON	ON	ON	OFF	OFF	OFF	OFF
D7	ON	ON	OFF	OFF	ON	ON	OFF	OFF
D8	ON	OFF	ON	OFF	ON	OFF	ON	OFF
Subdivision (micro step) ppr	5000	6400	8000	10000	12800	16000	20000	40000
D5	OFF	OFF	OFF	OFF	OFF	OFF	OFF	OFF
D6	ON	ON	ON	ON	OFF	OFF	OFF	OFF
D7	ON	ON	OFF	OFF	ON	ON	OFF	OFF
D8	ON	OFF	ON	OFF	ON	OFF	ON	OFF
D9	ON, double pulse: PU is positive pulse signal, DR is negative pulse signal
	OFF, single pulse: PU is pulse signal, DR is direction signal
D10	Self detect switch (OFF: accept external pulse, ON: the driver send pulse to make the motor work at the speed of 30r/m)

Ø CAUTION

1. The supply voltage shouldn’t exceed 130V.

2. Input control signal is 5V, current-limiting resistance should be connected when it is over 5V.and the drive is designed with 24V signal interface.

3. Input pulse signal is effective with the falling edge.

4. Alarm indicator ALM lights and the driver stops working when the driver temperature is over 80℃. It restarts working until the temperature falls to 50℃. The heat sink is needed when overheat occurs.

5. The distance between each drive should be less than 5cm when there are more than two drives run at the same time in a machine cabinet.

6. Alarm indicator ALM lights when overcurrent (short of load) occurs. Please check motor’s connection and other shorts and turn the power supply on after removing the trouble.

7. Alarm indicator ALM lights when no motor connected or poor connection. Please check motor’s connection and turn the power supply on after removing the trouble.

Ø Dimension Diagram

Ø Terminal Function
