It is widely used in elevator installation, shipyard, big tank, bridge, embankment and chimney.
Model
ZLP150
ZLP300
ZLP500
ZLP630
ZLP800
ZLP1000
Material
Steel/Steel with Dipping Zinc/Aluminum Alloy
Height
100m
Rated load(kg)
150
300
500
630
800
1000
1000
Length of platform(m)
1.5
3
5
6
7.5
7.5
10
Safety lock type
LSG20
LSG20
LSG20
LSG20
LSG20
LSG20
LSG20
Hoist model
LTD6.3
LTD3.0
LTD5.0
LTD6.3
LTD8.0
LTD10.0
LTD10.0
Volume(m³)
1.6
2.3
2.9
3
3.2
3.3
3.5
Weight(kg)
800
1700
1650
1850
2000
2300
2400
20GP container(pcs)
12
10
9
8
8
7
6
Counter weight(kg)
25*16PCS
25*28PCS
25*30PCS
25*36PCS
25*40PCS
25*50PCS
25*60PCS
Diameter of steel rope(mm)
8.3
8.3
8.3
8.3
8.6
8.6/9.2
9.2
Voltage(v)
380
380
380
380
380
380
380
ZLP series high operation suspending part name and size:
Main Products
Main Parts of Suspended Platform:
1.Electric Control Cabine:
Electric Control Cabine
Electric control system consists of many protection devices, eg.auto-limited, electric leakage proof, overheat protection, sudden-stop, over-current protection, it is reliable and very easy to operate.
Electronic Control Cabine
Electronic Control Cabine
Electronic Control Cabine
2.Hoist:
Hoist Model
LTD6.3
LTD8.0 a& S Type
Adjusted Specification
ZLP150, ZLP300, ZLP500, ZLP630
ZLP800
Rated Lifting Load
6.3KN
8KN
Lifting Speed
9-11m/min
8-10m/min
Motor Power
1.5KW
1.8KW-2.2KW
Steel Wire Rope Dia
8.3mm
8.6mm
3.Safety Lock:
Safety Lock Model
LST20/LST30/LSG20
Adjusted Specification
All models
Allowable Compact Force
20KN-30KN
Adjusting Range of Rope Lock Angle
3°~8°
Rope Lock Distance
≤100mm
