850T full automatic aluminum die casting machine specification:
Item
Unit
ZG-850
locking system
locking force
ton
850
tie-bar diameter
mm
180
space between tie-bar
mm
910*910
mold thickness
mm
400/950
die stroke
mm
760
shot position
mm
0/-250
injection system
plunger diameter
mm
90/100
injection stroke
760mm
570
injection force
KN
280-740
casting weight
kg
7/9/11
casting area
cm2
544-2285
casting flange diameter
mm
200
over height of flange
mm
20
ejection system
ejection force
KN
320
ejection stroke
mm
180
hydraulic system
motor power
kw
45
electrical furnace power
kw
90
operation pressure
kg/cm2
140
oil tank capacity
L
1300
oil / gas furnace capacity
kg
900
Other
machine size
mm
8500*2300*3450
machine weight
ton
38.5
Our Service
Professional service for pre-sales and after-sales :
Followed with the principle of "Customers are honored and Precision is reached for after precision," Zhen Gao will try best to provide professional service for customer .
* Provide plant layout and peripheral equipment configuration for new customers, make the machine more reasonable installation, safety.
* Install and adjust machine for customer , also train worker how to operate and solve normal trouble .
* After-sale service department and branch office will provide professional service for customer ,make sure machine normal working .
* Preventive maintenance: After-sale engineer will not regularly visit customers , give advice according to machine use, maintenance and adjustment etc. .
* We will provide various training ,to teach customer how to operate ZHEN GAO machine well ,and also organize many communication meetings of die casting technology.
Pre-Sales Service
* Inquiry and consulting support.
* Provide plant layout and peripheral equipment configuration for customer.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
