Export Brazil Paraguay Uruguay hot dip galvanized oval steel wire, animal

Product Overview

Description

 Hot Dipped Galvanized Iron Steel Oval Shape Wire For Cattle fence

Given that galvanized wire is classified according to the amount of zinc coating, the following table outlines the difference between standard, heavy galvanized and extra-high galvanized wire.



Nominal Diameter	Minimum Coating Mass (g/m2)
	Standard Galv.	Heavy Galv.	Extra-highGalv.
2.4 mm * 3.00mm	50	90	230
1.8 mm * 2.20mm	50	90	230
2.0 mm * 2.4mm	50	90	230
2.2 mm * 2.70mm	50	90	230
4.45mm * 5.25mm	35	50	230



 Tensile Strength (Mpa)

 The tensile strength is defined as the maximum load achieved in the tensile test, divided by the cross-sectional area of the wire test piece. Galvanized Wire is produced using soft, medium and hard grade wires. The following table specifies the tensile range according to the grade:



Nominal Wire Diameter	Bread Loading (kgf)
	Standard Galv.	Heavy Galv.	Extra-highGalv.
2.4 mm * 3.00mm	600	800	870
1.8 mm * 2.20mm	600	800	870
2.0 mm * 2.4mm	600	800	870
2.2 mm * 2.70mm	600	800	870
4.55mm * 5.25mm	600	800	870



Nominal Wire Diameter	Packing (meter)
	1	2	3
2.4 mm * 3.00mm	500	1000	1200
1.8 mm * 2.20mm	500	1000	1200
2.0 mm * 2.4mm	500	1000	1200
2.2 mm * 2.70mm	500	1000	1200
4.55mm * 5.25mm	500	1000	1200
