Hantek HT3005PA Triple Output PA Series 0 30V Voltage 0 5A Current Adjustable DC Power Supply 2 LED Display
- Category: >>>
- Supplier: Shenzhen Ever Good Electronic Co. Ltd.
Share on (62007470826):
Product Overview
Description
Hantek HT3005PA Triple Output PA Series 0-30V Voltage 0-5A Current Adjustable DC Power Supply 2 LED Display
Feature:
- SMD adhesive sheet element technology for internal PCB construction
- Two LEDS Display output current and voltage
- Multiloop high precision voltage regulation
- Progressive current regulation
- Dual termimal system Safety test style or expandable screw terminals
- Overload protection circuit
- Low ripple voltage:<1mVp-p
- Output polarity:positive or negative
- Rugged reinfirced metal frame construction
Specifications:
| Model | HT3003PA | HT3005PA |
| Output Voltage | 0-30V | 0-30V |
| Output Current | 0-3A | 0-5A |
| Input Voltage | 220V±10%, 50Hz±2Hz | |
| Source effect | CV≤1x10-4+3mV, CC≤2x10-3+6mA | |
| Load effect | CV≤2x10-4+3mV, CC≤2x10-4+6mA | |
| Ripple & Noise | CV≤1mVrms,CC≤10mArms | |
| Protection | current Limiting | |
| Voltage Accuracy | Reading±1% ±1 Digits | |
| Current Accuracy | Reading±2% ±2 Digits | |
| Environment | Ambient Temperature: 0-40℃; Humidity: <90% | |
| Weight | About 5KG | About 6KG |
