Manufacturer Low Temperature House Inverter Air Source Heat Pump
- Category: >>>
- Supplier: Foshan Airosd Thermal Technology Co. Ltd.
Share on (62007516148):
Product Overview
Description
This series heat pump can work in very low climate area down to -30℃. The heat pump is equipped with EVI compressor and high efficiency in low temperature conditions, its heating performance is higher by 50%-80% than normal heat pump. It is widely used in cold area and even work well at -30℃, can be matched with fan coil, floor radiator heating, it is suitable for villa, hotel, office, etc.
Manufacturer Low Temperature House Inverter Air Source Heat Pump
Main Features
1) Heating Capacity range: 9kW, 14kW,17KW, 32kW, 45kW, 65kW,75kW.90KW,150KW
2) Copeland EVI compressor and Schneider electrical components.
3) Working ambient temperature down to -30℃.
4) Automatically defrosting.
5) Intelligent controller and adjustment by microprocessor.
6) High efficiency tube in shell heat exchanger.
7) Match with floor heating, fan coils, and Central AC function.
OPTIONAL:
Galvanized metal cabinet or stainless steel cabinet.
Refrigerant: R22 and R407C and R410a is possible.
Model | DKFXFC-009SCI | ||
Ambient temp.range | -30~+43℃ | ||
Power supply | 220V 1N~50Hz | ||
Electric shock proof grade | Class I | ||
Protection grade | IPX4 | ||
Heating Capacity/COP | 9.4KW /4.1 | ||
Cooling Capacity/COP | 7.5KW /2.6 | ||
Low-temperature heating(A-12W41)/COP | 5.9KW /2.3 | ||
Normal temperature heating(A7W45)/COP | 9.0KW /3.6 | ||
Rated cooling input power | 2.9KW | ||
Low temperature heating input power | 2.6KW | ||
Normal temperature heating input power | 2.5KW | ||
Max.working current | 20A | ||
Compressor | Type | Scroll | |
Quantity | 1 pcs | ||
Fan | Quantity | 1 pcs | |
Max. water temperature | 60℃ | ||
Refrigerant type/Weight | R407C/3.0 kg | ||
Water yield | 1300 L/h | ||
Dimension (width×depth×high) | 1087×435×901 (mm) | ||
Packing dimension(width×depth×high) | 1230×500×1050 (mm) | ||
Noise | 54dB(A) | ||
Net weight | 70KG | ||
Gross weight | 80KG | ||
Circulating pipe diameter | G1"external thread (inch) | ||
Q: Are you heat pump supplier of trading company or manufacturer ?
A: We are a manufacturer of R&D and production heat pumps which is located in Foshan city, Guangdong province of china. We can provide different kinds of heat pumps as you need, such as EVI inverter heat pump, DC inverter heat pump and swimming pool heat pump ect.. We also can provide OEM/ODM services.
Q: How long is the product lifespan?
A: In general, with proper maintenance, its lifespan can last up to more than 15 years.
Q: If the temperature drops below zero, will the air source heat pump still work?
A: Yes, AIROSD Air Source heat pumps with EVI technology can operate high efficiently when the temperature downs to -30°C.
Q: What is the benefits of air source heat pumps?
A: One Bill : Air source heat pump runs on electricity, so there's no need to pay for gas, oil or solid fuels to heat your house. You eliminate the standing charge for mains gas supply, delivery charge for oil and solid fuel, etc. .
Save space : Air source heat pump system is compact, and requires no storage space for fuel.
Energy Saving : Air source heat pump can make energy saving up to 75% than traditional electrical water heater.
