Алюминиевая плавильная печь, стеклянная печь, низкая регенеративная низкая азотная горелка для видов топливного газа, угля и т. д.
- Category: >>>
- Supplier: Foshan Sunlor Technology Co. ltd
Share on (62008639642):
Product Overview
Description
| 1. Products introduction | |
| products name | alluminum melting furnace glass furnace A-low Regenerative low nitrogen burner by kinds of fuel gas, coal etc |
| Material | Steel |
| Power | 760kW,1170kW,1600kW,2300kW, 3500kW,4600kW,5800kW |
| Adjust Ratio | 10:1 6:1 |
| Application | Continuous or intermittent heating furnace,melting furance,Bogie hearth furnace, High Temperature Air Heating Furnace,Glass melting aluminum,Ladle refining furnace,Forging furnace,Non-ferrous metal heating furnace |
| 2. Advantage of A-low Regenerative low nitrogen burner | |
| High efficient heat utilization up to 55% | |
| Significant reduction in CO2 emissions | |
| NOx emissions reduction | |
| No heat exchanger required, refractory masonry chimney because of very low exhaust smoking temperature | |
| High performance regenerative pellets with long service life | |
| Extremely high benefit return | |
| 3. Characteristic of A-low Regenerative low nitrogen burner | |
| Inspection:UV probe or ionization | |
| The preheating temperature reaches 85% of the furnace temperature. | |
| Maximum temperature: 1350℃ | |
| Smoke exhaust mode:Exhaust air blower | |
| Control way: Flow control,Open and close pulse control | |
2. Selection sheet
| Model | A-LOW-025 | A-LOW-050 | A-LOW075 | A-LOW-100 | A-LOW-150 | A-LOW-200 | A-LOW-250 |
| Power | 760kW | 1170kW | 1600kW | 2300kW | 3500kW | 4600kW | 5800kW |
| Airvolume(Cubic/hour) | 740 | 1130 | 1555 | 2250 | 3390 | 4525 | 5600 |
| Air pressure(Kpa) | 0.62 | 0.62 | 0.62 | 0.62 | 0.7 | 0.7 | 0.7 |
| Gas pipe diameter(DN) | 50 | 50 | 80 | 100 | 100 | 100 | 150 |
| Flame length(mm) | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4300 |
| Flame diameter(mm) | 490 | 525 | 575 | 620 | 720 | 800 | 900 |
| Natural gas | |||||||
| burner gas pressure (mbar) | 12.5 | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 |
| Adjust ratio | 10/1 | 10/1 | 10/1 | 10/1 | 10/1 | 10/1 | 10/1 |
| Oil | |||||||
| burner gas pressure (mbar) | 3.74 | 3.74 | 3.74 | 3.74 | 3.74 | 3.74 | 3.74 |
| Adjust ratio | 6/1 | 6/1 | 6/1 | 6/1 | 6/1 | 6/1 | 6/1 |
