New VOSTOSUN 9 25m3/h concrete Shotcrete Robot KC3017 price
New VOSTOSUN 9-25m3/h concrete Shotcrete Robot KC3017 price
New VOSTOSUN 9-25m3/h concrete Shotcrete Robot KC3017 price
New VOSTOSUN 9-25m3/h concrete Shotcrete Robot KC3017 price
New VOSTOSUN 9-25m3/h concrete Shotcrete Robot KC3017 price

New VOSTOSUN 9 25m3/h concrete Shotcrete Robot KC3017 price

Share on (62009128995):


Price:

Quantity:


Product Overview

Description




Product Description



Applications



No.ItemData
1CompleteWeight(T)17
machineTravelling speed(km/h)0~18
 Grade ability(°)25
 Ground clearance(mm)400
 Steering4 wheel driving/steering/crab
 Outside dimension(L×W×H)(mm)8265×2500×3200
2Pumping systemTheoretical pump capacity (m³/h)4~30
Filling height(mm)<1200
Max.aggregate size(mm)≤16
Max. theory outlet pressure (MPa)7.5
Pipe diameter(mm)125
Hopper capacity(L)600
3MotorRated Power(kW/rpm)55/1480
Rated voltage(V)three-phase/380(optional)
4EngineMode4 cylinder liquid-cooled diesel engine
Rated power(kW/rpm)82/2200
Diesel tank volumn (L)120
5Air compressorModeScrew type
Rated Power((kW)75
Max.wind flow(m³/min )13.5
Exhaust pressure(MPa)0~0.7
6Shotcrete BoomBoom modefoldable, rotate, telescopic
Max.spary areaUpward(m)17
Forward(m)15
Downward(m)8
Width(m)30
Main boom rotate angle(°)270
Main boom tilt angle(up/down)(°)60/23
Main boom telescopic length(mm)2000
Telescopic boom rotate angle(°)(L/R)180/60
Telescopic boom tilt angle(up/down)(°)30/62
Telescopic boom stretch length(mm)2000
Nozzle rotate(°)360
Nozzle swing (°)240
Nozzle brush(°)8x360 continuous
Nozzle diameter(°)80
7AdditiveFlow rate(L/h)0~1200
systemWorking pressure(MPa)1.2
 Tank volumn(L)1000
8Cleaning SystemFlow rate(L/min)14
Working pressure(MPa)14
Motor rated power(kW)4
9Electric SystemOperate modewireless romote control
Control modePLC + touchscreen display
10Cable ReelCable length(m)100
Power Source(V/Hz)380/50(optional)
Electric current(A)400
Product Advantages



More

Company Information
Why Choose Us

Ø CORE VALUE:

Integrity, Profession, Efficiency, Gratitude, and Responsibility

Ø GOAL AND VISION:

Committed To Becoming a Professional Solution Provider For Centralized Procurement And Supply Of

Engineering, Mining And Mineral Powder Processing Projects.

Ø OUR MISSION:

Your Requirements For Equipment Selection, Quality, Cost, Delivery, Risk Control And After-Sales Service,

Your Service Requirements For Overseas Markets,They Are Our Existing Value And Unremitting Pursuit!

FAQ

Q:What's your payment term?
A: We accept T/T(30% down payment and balance before shipping) and L/C mostly. But if you prefer other payment terms please contact us for further information.

Q: Whats's the warranty time?
A:From the date of shipment,1 year or 1500 working hours,whichever comes first.

Q:What`s the international project experience?
A: Kazakhstan Astana Capital Moving Projuct,
Russia Voronezh Nuclear Power Station,
Shanghai Pengxin Mining Congo(Gold) Copper Project,
Equatorial Guinea National Highway Equipment General Contracting

Q:What`s the technical support or partnership?
A: Institute of Powder Engineering, Tsinghua University.
Chinese Academy of Geological Sciences.
China Academy of Building Research
