\t1, Working environment Temperature: 1 0℃ ~ 40℃ Relative temperature: 30% ~ 75% Atmospheric pressure: 700hPa ~ 1060hPa; Power supply voltage: AC 220V ± 22V, 50Hz ± 1Hz; DC 12.6V ± IV Air supply pressure: 0.35MPa ~ 0.6Mpa
|
| \t 2,input power:DC:≤17W;AC:≤54W; |
| \t 3, Ventilation quanity: 350ml~900ml continuously adjustable |
| \t 4,Pressing depth: 30mm~70mm continuously adjustable, each adjustment 5mm; |
| \t 5,Pressing frequency: 80 times/minute, 90 times/minute, 100 times/minute, 110 times/minute, 120 times/minute continuously adjustable; |
| \t 6,Press the ventilation ratio: 30: 2,15: 2, separete continuously press three operation modes can be switched; |
| \t 7,Color: As the picture shown |
\t8,with a separate continuous ventilation function, ventilation frequency 8-16times/minute continuously adjustable; |
| \t 9,Electricity, according to the low voltage alarm, start the suspended function; |
\t10,The pressure is not enough to alarm, the pressure depth is reduced automatically, and the manual recovery after air pressure recovery must be deep. |
| \t 11,Pressure depth of 50MM and above to confirm function |
\t12,Default mode:Press the ventilation ratio: 30: 2,press depth 30mm,press frequence 100 pcs/min; Ventilation quanity 350ML |
| \t 13,vertical adjustment height: minimum 155mm, maxium 315mm; |
| \t 14,outsize:the main machine size:L×W×H=660 ㎜×566 ㎜×(526.5~686.5)㎜ |
