3 and 4 Roller machines for cylinder, manual sheet rolling machine, mechanical metal bender

Product Overview

Description

3 Roller machine plastic sheet cutting tool, plate sticking machine, precision levelers machine tool



1.  used to coil plate into different sharps such as cylindrical form, conic form and arc, it adopted Japan hydraulic technical



2.  Top roller can do vertical and level motion, up and down, parallel translation is display



3.  Upper roll can move in vertical and level include pre-bending function



3.  Adopted many points to lubricate Universal Plate Rolling Machine



4.  Mechnical, hydraulic, electricity all system set over loading protect device



5.  Fitted quality CNC system fault check itself automatically, error give an alarm, mistake protection and so on pipe bener



6.  Adopt hand switch button box easily operate Universal Plate Rolling Machine



7.  Simple foundation equipment, it can move to operate



3 Roller machine plastic sheet cutting tool, plate sticking machine, precision levelers machine tool



Model W11S	Max rolling thickness	Max pre-rolling thickness	Plate width	Diameter of upper roller	Main motor power
	(mm)	(mm)	(mm)	(mm)	(kw)
12*2000	12	10	2000	250	5.5
16*2500	16	12	2500	300	15
18*3000	18	14	3000	350	15
20*3000	20	16	3000	375	22
30*3000	30	25	3000	450	30
40*4000	40	35	4000	630	55
45*4000	45	40	4000	660	75
50*4000	50	45	4000	700	75
60*4000	60	55	4000	780	90
70*4000	70	65	4000	840	110
80*4000	80	75	4000	900	110
90*3000	90	80	3000	800	90
100*4000	100	85	4000	940	2*55
110*4000	110	95	4000	990	2*75
120*3000	120	100	3000	960	2*55
130*3000	130	110	3000	980	2*75
150*3000	150	120	3000	990	2*75
160*4000	160	130	4000	1260	2*90
