Granulated pharmaceutical industry: tablet granule, granules, capsules, granules. Granulated food industry: cocoa, coffee, milk powder, granule juice, spices and the like. Other industries granulation: pesticides, feed, fertilizer, pigment, dyestuff and so on. Powdered or granular drying wet materials.
Principle Material powder particles in the material container (fluid bed) was boiling in a fluiding state by the heated air is preheated and mixed after purification, the binder solution sprayed into the spray, so some particles to contain a binder pellets, since the hot air drying of materials continue to make pellets in the water evaporates, the adhesive sets, this process is repeated continuously, form an ideal, uniform microporous spherical particles.
Typical technical data
Item
Unit
5
60
120
200
500
Container
Volume
L
22
220
420
670
1500
Diameter
mm
400
1000
1200
1400
1800
Capacity
MIn
Kg
4
30
80
100
250
Max
Kg
6
90
160
300
750
Fan
Capacity
m³/h
1200
3000
4500
6000
8000
Pressure
mmH2O
375
950
950
950
950
Power
Kw
4
11
18.5
22
45
Steam consumption
Kg/h
23
141
211
282
451
Electrical heater
Kw
18
45
63
96
123
Compressed air need
m3/min
0.9
Heating tempreture
℃
Environmental T.-120
Steam pressure
Mpa
0.3-0.6
Working time
Min
45-90
Weight
Kg
700
1100
1300
1500
2000
Overall dimension
M
1.2*0.7*2.1
1.85*1.4*3
2.2*1.65*3.3
2.34*1.7*3.8
3*2.25*4.4
All data are used for reference only. According to different conditions of material and customer’s requirements, people can customize the machine.
