Automatic Conveyor roller making machine/ Shaft milling machine/ Idler roller welding machine

1.Uses

Used for the synchronous processing for the flat and groove at both ends of the roller shaft

2. Characteristics

Four sets of milling devices work simultaneously to guarantee the symmetry of the flat and groove of the roller shaft
The clamping,positioning and tool feeding are driven by hydraulic system, which enables the tool feeding smooth and the processing is highly precise.

3. Parameter

spindle speed	high speed and low speed
roller shaft dia	φ20-φ40
roller shaft length	160-2400mm
shaft groove and flat width	6-30mm
milling depth	0-5mm
spindle motor	3kw*2(sets)
pump motor	1.5kw
hydraulic system working pressure	4-6mpa
hydraulic system flow	31L/min
cooling pump motor	40w
OEM	Available
