Mato Total Station MTS602R Reflectorless Total Station 400m to 500m China Brand new
- Category: >>>
- Supplier: Shanghai Magcach Technology Co. Ltd.
Share on (62012041322):
Product Overview
Description
Product Description
Mato Total Station MTS602R Reflectorless Total Station 400m to 500m China Brand new
Quick, accurate distance measurement 0.8second
·Visible laser for aiming easy
·Reflectorless: distance measurement 300-500m
·Reflective sheet: midding distance measurement 800m
·Single prism: long distance measurement 5000m
·Surveying tasks are solved quicker, easier and more ·comfortably by integrated survey programs
·Special function of data upload and download
·Large internal memory to record 50000 points,memory manament system
MODEL | MTS-602L | MTS-602R | MTS-605R |
Telescope | |||
Image | Erect | ||
Magnification | 30X | ||
Effective Aperture | 45mm(DTM 50mm) | ||
Resolving Power | 4" | ||
Field Of View |
1°30' | ||
Minimum Focus | 1.5m | ||
Distance Measurement(under Fair Weather Condition) | |||
None prism |
| 500m | 500m |
Range 1P | 2.0km | 3.0km | 3.0km |
sheet | 800m | 3.0km | 3.0km |
Accuracy | 2mm+2ppmxD | ||
Minimum Count | 1mm | ||
Distance Unit | ft.Or m selectable | ||
Measuring Time |
| ||
Fine | 1.8sec.(first time2.5sec.) | ||
Tracking | 0.4 Sec. | ||
Maximum display | 999999.999m | ||
Atmospheric Correction |
| ||
Temperature | C or F | ||
Atmospheric Pressure | hPa/mmH/inHg | ||
Atmospheric Deflection & |
| ||
Earth Curvature Correction | k=0.14/0.20/0 | ||
Prism Constant | 0 mm / 30 mm | ||
Angle Measurement | |||
Measurement Method | Incremental Photoelectronic Encoder | ||
Detection Method |
| ||
Horizontal | Dual | ||
Vertical | Dual | ||
Accuracy | 2" | 2" | 5" |
Minimum Readout | 1"and5" | 1"and5" | 5"and10" |
Sensitivity of Vials | |||
Plate Vial | 30"/2mm | ||
Circular Vial | 8'/2mm | ||
Vertical Compensation | Available | ||
Type | Liquid-electric detection/Plate level | ||
Compensation Range | +/-3' | ||
Resolution | 1" | ||
Optical Plummet | |||
Image | Erect | ||
Magnification | 3X | ||
Focus Rang | 0.5m-infinity | ||
Display | Double Side, LCD, Four-line Display | ||
Data Port | RS-232 | ||
Battery | Lithium Rechargeable | ||
Voltage | 7.4VDC | ||
Operation Time | Distance and angle measurement: 8.5hours; Angle measurement 30 hours | ||
Charging Tine | 2 hours | ||
Packaging & Shipping
Our Services
1. For instruments (total station,theodolite,GNSS,auto level), we offer 1 year warranty,for accesories(Prism,pole,tripod ,levelling staff).we offer 6 months warranty,from the day you get the product.
2.For product within the warranty period,please send us photos to show the problem.And then we will decide to send you parts or you send the instrument back to us to repair.We will be responsible for the double-run freight and other cost.Please make sure to contact us first instead of sending the damaged parts direct to us.
3.For problem out of the warranty period or warranty liability,we will judge the probelm and quoted for you.You need to pay double-run freight and the maintenace cost.
4.For all instrument we provide life-long technical support.
Remark:Improper use of the instrument and man-made damage of the instrument is not coverd in warranty liablity.Warranty only aimed at the problem caused by the product quality.
