Stainessl steel food grade wine filter press storage grape fermentation wine tank
- Category: Fermenting Equipment >>>
- Supplier: Wenzhou Leno Machinery Co. Ltd.
Share on (62013487598):
Product Overview
Description
Stainessl steel food grade storage grape fermentation wine tank
| Stainessl steel food grade storage grape fermentation wine tank | ||
| Profile/type | Single layer tank | Double layer tank |
| material | SS304 or SS316L | |
| Volume | 50L-20T (Customized) | |
| Pressure | 0-1Mpa | |
| Tank Type | Vertical type | |
| Structure | one layer | Inner layer+ Dimple Jacket |
| Cooling way | No | cooling water |
| PARTS DETAILS | 1.Top manhole / side manhole | |
| 2.Various types of CIP cleaners | ||
| 3.Sterile respirator | ||
| 4.Adjustable Legs | ||
| 5.Inlet and Outlet sanitary valve. | ||
| 6.Thermometer (According to customer requirements ). | ||
| 7.Liquid level meter and lever controller (According to customer requirements) . | ||
| 9.Ladder | ||
This type of wine fermentation tank is primarily intended for maceration of grape pomace,but it also can be used as a classic wine storage tank.
The circulation pipe and spray ball enable the must be pumped over the cap, which helps the maceration. Slope bottom provides an easy discharge of liquid.The large rectangular manhole makes the emptying and cleaning of tank interior easy and simply. Cooling jacketed is for controlling the fermenting temperature perfectly.
Technical Parameter
| Model | Effective volume(L) | Dimension of tank(D*H)(mm) | Total Height(mm) | Agitator speed(r/min) |
| RST500 | 500 | Φ800x900 | 1700 | (According to customer requirements) |
| RST1000 | 1000 | Φ1000x1220 | 2100 | |
| RST2000 | 2000 | Φ1200x1500 | 2500 | |
| RST3000 | 3000 | Φ1600x1500 | 2600 | |
| RST4000 | 4000 | Φ1600x1830 | 2900 | |
| RST5000 | 5000 | Φ1800x2000 | 3150 | |
| RST6000 | 6000 | Φ1800x2400 | 3600 | |
| RST8000 | 8000 | Φ2000x2400 | 3700 | |
| RST10000 | 10000 | Φ2100x3000 | 4300 | |
| We can customize the equipment according to customers' requirment. | ||||
More details picture
Company Strength
More Related Products:
Certifications
Buyer Feedback
Packaging & Shipping
FAQ
| Q1 | Are you trade or manufacturer? |
| A | We are a factory with an international sales company specialized in support for global distributors. |
| Q2 | Can you provide instant technical consulting services? |
| A | We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days. |
| Q3 | What's the difference between Ready-To-Ship and Customized products? |
| A | Some of RTS standard products are in stock and ready to ship in 2-3 days. |
| Q4 | What is the payment terms? |
| A | We accept Alibaba Trade Assurance Order, also can T/T and L/C. |
| Q5 | How to choose the shipment way? |
| A | It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers) |
| Q6 | How about the after-sales service? |
| A | Fast after-sales support. Our products have a one-year warranty and free permanent consulting services. |
