Product Overview

Description

24VDC MF21 Tank water level sensor float type



Kaidi Fluid Controls will get you the right float switch or liquid level sensor for your application! Whether you need an off the shelf float switch or a custom designed liquid level sensor, we can help! Strain Measurement Devices is a technically driven design and manufacturing firm dedicated to helping customers solve their toughest sensor and measurement problems. KAIDI's talented staff has been designing custom sensors to measure force, pressure, temperature, weight, torque, liquid level and many combinations.



Contact Capacity:	AC220V/1A DC24V/0.5A
Pressure rating:	<=1.5 Mpa
Specific gravity:	0.7
Output:	SPST  NO/NC
Temperature rating:	-20~130°C
Protection rating:	IP68
Probe material:	SUS304/SUS316L
Body material:	SUS304/SUS316L
Mounting type:)	1/8”PF(Customizable
Cable length:	500±10mm
Installation:	Vertical
Anti-explosion:	No
