Waterproofing Membrane for Drinking Water Tanks

Product Overview

Description

Application Area

• Drinking Water
• Reservoirs and Tanks as Top Layer
• Water Channels and Water Tanks as Top Layer
• Drinking and Potable water transmission systems

Application Advantages

• High Quality meeting EN 13967 Quality Standards
• Vapor Permeable structure
• Antimicrobacterial Features
• Does not change of water physical and chemical properties
• Does not permit generation of bacteria and mosses on the surface.
• Recyclable environment-friendly material that includes no heavy metal
• High flexibility value.
• Dimensionaly stable material
• Ability to maintain its flexibility in -25C degrees temperature
• High tear resistance and impact strength
• Qualified and easy application options with heat air welder
• Provides waterproofing in temperatures between -35 C and 85 C degrees
• Homogeneous product that has dissolution and decomposition resistances.

Tested Features	Minimum Required Value	Test Result	Unit	Test Method
Waterproofing	impermeable	impermeable	-	EN 1928 (B)
The end of the aging water resistance	impermeable	impermeable	-	EN 1926 ve EN 1928 (A)
Determination of visible defect	perfect	perfect	-	EN 1850-2
Value of tensile strength	>15	>18	N/mm2	EN 12311-2
Value of elasticity	>250	>320	%	EN12311-2
Static Load Resistance Value	>20	>20	Kg	EN 12730 (B)
Value of Impact Resistance	>450	>900	mm	EN 12691 (A)
Tear Strength Value	>300	>330	N	EN 12310-1
Reaction to Fire	E Class	E Class	-	EN 13501-1
Value of joint strength	>600	>750	N/50mm	EN 12317-2
Determination of Water Vapor Permeability	25500 ± 7500	25500 ± 7500	µ	EN 1931
Junction Where The Value of Peel Strength	>150	>155	N/50mm	EN 12316-2
Dimensional Stability	<2	<2	%	EN 1107-2
Stability of Elasticity in The Cold	< -25	< -25	°C	EN 495-5

PRODUCT SIZES

Thickness	Width	Length	Colour*	Roll m2	Roll Weight
1,2mm	2,10mt	25	Blue	52,5m2	82kg
1,5mm	2,10mt	20	Blue	42m2	98kg

(*) Different Colours Are Possible According To Demand
