Centrifuge Machine For Agro

Product Overview

Description

CE and ATEX Certifiied, GMP and cGMP Compliant. Validation Documents like OP, IQ, PQ & DQ provided. We are one of the largest Manufacturer and Exporter of Centrifuge Machine, CGMP Centifuge Machine,Centrifuge machines are available in various types like Bottom Discharge Centrifuge, Bag Lifting Centrifuge, Pharma Peeler Centrifuge and in various sizes like 12 inch, 24 inch, 36 inch, 48 inch dia customization can also be done. Our Well Engineered centrigue are supplied worldwide with all document required for GMP, USFDA approval.



This type is Bottom discharge type centrifuge machine.



TECHNICAL SPECIFICATIONS

MODEL  SS-24  SS-36  SS-48  SS48D  SS-60 Basket dia. (mm) 610 915 1220 1220 1524 Basket Ht. (mm) 305 457 510 812 762 Basket Speed (rpm) 1400 1025 900 800 700 Max permissible load on Basket (Kg) 70 250 325 350 500 Motor (HP) 3 8 20 30 40 Vol. underlip (Ltrs.) 50 200 295 500 665 Centrifugal Force 668 537 552 436 417 Filtration Area 0.58 1.31 1.95 3.11 3.65 Length (mm) 1400 1800 1500 1600 2400 Width (mm) 900 1250 2100 2200 2000 Operating Height (mm) 1300 1500 2400 2400 2400 Weight of Machine (Kg) 1200 2800 3800 4200 6500
