High Quality Cold Chamber Standard Aluminum Alloy Die Casting Machine

Product Overview

Description

High Quality Cold Chamber Standard Aluminum Alloy Die Casting Machine,  with Siemens PLC and Japanese valves , well known brand " EAGLE "  machine with steady performance and competitive price , professional export staff ensures the prompt sea shipping and customs affairs , professional engineer ensures prompt after-sales service !



please click each picture below for more details





 Why choose us ?

1. More than 26 years history
2. Competitive price with high quality
3. Overseas service available
4. Self owned estate guranteed long development
5. Own patent techinics and CE
6. Normal models of  machines in stock
7. Leading enterprise of die casting machine in China
8. Wellknown brand of valves,electronics and Simens PLC

9. many models from 12 ton to 4000 ton for choose





Please click the picture below,  you can watch the video of our factory profile , or the video on "homepage of our website" .  Thank you!!











Eagle die casting machine most advantagement :

1. Strong locking force and injection force

2. High efficiency, saving power

3. Low oil temperature contorl

4. Auto computer control , easy operation

5. Correspondingly fast, high and stable quality

6. Automatic lubrication system, improve machine life.

7. Fast and steady gear mould adjustment , guarantee machine long life.

8. Professional service for all customers

9. CE standard ,  many patents

10. More than 26 years experiences







                  High Quality Cold Chamber Standard Aluminum Alloy Die Casting Machine





DCC300T cold chamber die casting machine
Project	clamping force	clamping stroke	die height(MIN-MAX)	platen size (HXV)	inner space between tie bar	tiebar diameter	intensifier injection force(with intensification )	injection stroke
Parameter	3000	460	250-655	880*900	575*575	115	340	430
Unit	kN	mm	mm	mm	mm	mm	Kn	mm
Project	plunger diameter	shot weight	casting pressure (with intensification )	casting area	maximum foundry acreage	shot injection postion (below center line )	plunger penetration	diameter of pressure chamber flange
Parameter	50  60 70	1.5  2.2  2.9	166 122  85	170 245 335	680	0,-125	150	110/101.6
Unit	mm	kgs	Mpa	cm2	cm2	mm	mm	mm
Project	height of pressure chamber flange	ejector force	ejector stroke	hydraulic working pressure	driving motor	hydraulic oil tank capacity	machine weight	machine dimensions(L*W*H)
Parameter	10/12	140	100	14	18.5	840	11000	6500*1450*2600
Unit	mm	kN	mm	Mpa	KW	L	Kg	mm













FAQ of High Quality Aluminium Injection Molding Machine Cold Chamber Die Casting Machine

 1. Q: Is your company a trading company or manufacturer?

A: Our company is a manufacturer, founded in 1997, we have been focused on the production of die casting machine for more than 26 years.

Leading enterprise of die casting machine in China .



2. Q: Does your machine easy to operate? What if I have no operating experience before?

A:Our machine have computer control system with computer screen display, it is very easy to operate.What’s more, we have English instruction and operating video with English annotation. All of these will be send you with the machine.



3. Q: How's your products?

A:Our good quality is built on superior material, imported from  Germany Siemens PLC and touch screen,Japanese Valves ,France Omron and Schneider Electronic and so on. We have professional engineers and experienced work team.



4. Q: Where your machine been exported before?

A: Our machine have been exported to all over the countries ,such as USA , Brazil , Mexico , Bulgium,Turkey,Ukraine ,  Pakistan,India ,Egypt ,Venezuela, Vietnam , Columbia , Nigeria etc.



5. Q: How long is the delivery time?

   A: Generally 20-30 days for production according to the quantity.



6. Q: How about installation and commission overseas?

A: we supply overseas service , customer only needs  to arrange for the engineers' flight tickets and hotel,food.



7.  Q: How about the quality guarantee period?

A: One year . After sales service will be for the machine whole life.



8. Q:How can you guarantee the production quality ?

A: We have strictly quality control system in our production process.We are honest and reliable supplier who never cheat the clients.With us the money is safe and any quality issue the payment will be refundable.



9.  Q: What should I do if I want to order?

A:We would need you to provide your as much detail as possible about your requirements. So we suggest a most suitable design for you!
