Gooxi SY308 S16R High and Stable Computing Performance Micro Cloud Server
- Category: >>>
- Supplier: Shanghai Harmuber Technology Development Co. Ltd.
Share on (62021069197):
Product Overview
Description
SY308-S16R
Product Description
Introduce
SY308 is high density Micro-Cloud Server. It supports 8 nodes hot-swap, and each node works independently, end user can config node’s quantity accordingly. It is widely applied to cloud computing, searching engine, web hosting, CDN, video server, social network/FTP and so on.
Features
High and Stable Computing Performance
Gooxi own designed G3SCL-4B motherboard; based on Mehlow platform and LGA1151 socket, support the latest Intel Xeon E-2100 series processor, TDP up to 95W,work stably on full loading.
customized on demands, collocate easily
The whole system supports up to 8 nods hot-swap, each node works independently, end user can configure the quantity and specification according to demands, such as storage expansion, Mezzanine card or PCIe card.
Excellent ability of storage expansion
Each node support 2*3.5”SATA/SAS HDD, the whole system up to 16*3.5”SATA/SAS HDD;
Each node support 4*DIMM slot dual channel, up to 64GB DDR4 ECC UDIMM;
Each node support 2*M.2 NVMe SSD PCIe x2.
Flexible I/O
Each node support 4*GbE Intel I-210AT, the whole system up to 32*GbE;
Option Mezzanine Card NIC 2*GbE I350 or 2*10GbE 82599 SFP+;
Each node with 1*1PMI port, support remote management, based on ASpeed AST2500;
Each node with 1*HDMI port (work with HDMI to VGA adapter);
Each node support rear 2*USB3.1.
Centralized cooling, Intelligent temperature control
4*8038 hot-swap fans;
1+1 redundant 1600W CRPS hot-swap platinum efficiency power supply.
Specifications
Spec
| System | |
Model | SY308-S16R |
HDD
|
Each node support 2*3.5”SATA/SAS HDD, the whole system up to 16*3.5”SATA/SAS HDD
|
Dimension
|
710mm*448mm*132.2mm(L*H*W)
|
Processor
| Support Intel® Xeon® E-2100 processor seriesseries processor Max 6Core+GT2, Socket H4 (LGA1151) ,up to 95W CPU
|
Chipset
| Intel® PCH C242/C246 |
Motherboard
| G3SCL-4B |
Memory |
Each node support 4*288 pin DDR4 ECC UDIMM slot, each node up to 64GB DDR4-1600/1866/2133/2400/2666 Each slot support 2GB, 4GB, 8GB,16GB The whole system up to 512GB
|
PCIe expansion
|
Each node support standard 1*PCIe x16 slot half height(can change it to 2*PCIe x8 riser card)
|
SATA | Each node support 6*SATA3.0 connector, 2 of them connect with internal 2*2.5” port, other 4 connectors reserved. |
SAS | Each node can install standard SAS card to support 3.5” SAS HDD (need install riser card and cable) |
M.2 | Each node support 2*M.2 NVMe SSD (PCIe x2, option dimension:2240/2280/22110) |
LAN | Each node support 4*I210AT GbE LAN |
VGA | Aspeed AST2500 graphics, HDMI connector, need a HDMI to VGA adapter |
| USB | Each node support 2*USB3.1 |
Power Supply | 1+1 redundant 1600W CRPS power supply hotswap |
PMI | Each node with 1*NCSI shared I210 IPMI 2.0, 1*BMC I2C debug port |
Fans | 4*8038 12V fans hotswap |
Network | 2*1GbE (i210AT) on board, option Mezzanine NIC (2*GbE i350 or 2*10GbE 82599) |
Security | TPM/TCM(option); |
Management
| On-board iBMC management module,support IPMI,SOL,KVM Over IP,virtual media management |
Compatibility
| Microsoft Windows Server,Red Hat Enterprise Linux,SUSE Linux Enterprise Server,CentOS,Citrix Xen Server,Vmware ESXi,Linux KVM,Ubuntu |
Virtualization
| VMWare ESXi 6.0 |
Temperature | Operation:5ºC - 35ºC(no direct light); Expansion :5ºC - 40ºC(limited configuration); Transport/Storage:-40ºC - 65ºC |
Humidity
| Operation Humidity:30% - 80%( Non-Condensing) |
Product Picture
