10 Years Life Span 12V 250Ah AGM Deep Cycle Battery for Solar Panel
- Category: >>>
- Supplier: Yangzhou Zhongming Technology Co. Ltd.
Share on (62021522575):
Product Overview
Description
10 Years Life Span 12V 250Ah AGM Deep Cycle Battery for Solar Panel
Product Description
Model | 6-CNJ-250 | |
Nominal voltage | 12V | |
Nominal capacity(10hr) | 250.0AH | |
Dimensions | Length 525±3mm Width 268±3mm Container Height 219±3mm | |
Approx. weight | Approx.65 kg | |
Container material | ABS | |
Rated capacity 25℃/77℉ | 278.0AH/20 hour rate (13.9A) 228.0 AH/5 hour rate (45.7A) 151.2AH/1 hour rate (151.2A) | |
Internal resistance | Approx 2.0mΩ | |
Operating temp. range | Discharge : -15- 50℃ (5 -122℉) Charge : 0 -40℃ (32- 104℉) Storage : -15- 40℃ (5- 104℉) | |
Nominal Operating temp. range | 25 ± 3℃ (77 ± 5℉) | |
Charge (constant voltage )25℃(77℉) | Float | Initial Charging Current less than 50.0A. Voltage 13.6V-13.8V |
Cycle | Initial Charging Current less than 50.0A. Voltage 14.4V-14.9V | |
Capacity affected by temperature | 40℃ (104℉) 102% 25℃ ( 77℉) 100% 0℃ ( 32℉) 85% -15℃ ( 32℉) 65% | |
Self-discharge Capacity 25 ℃(77℉) | Remaining capacity after 3 months of storage :90% Remaining capacity after 6 months of storage:80% Remaining capacity after 12 months of storage:62% | |
Battery Construction | ||||||||
Element | Electrolyte | Positive Plate | Negative Plate | Container | Cover | Safety valve | Terminal/Wire | Separator |
Material | Colloidal silicon | Lead dioxide | lead | ABS | ABS | Rubber | Lead/Copper | Fiberglass |
More detailed infomation or latest catalogue,send enquiry now.
Related Products
Battery Applications
Company introduction
Yangzhou Zhongming Technology Co.,ltd is a professional manufacture of new energy products,
Mainly including solar street lights,solar battery,solar panel,solar power system,etc.
We insist on quality first,customer first.
Our products are qualified with CE,ROHS,IEC,FCC,TUV,CCC,ISO,SONCAP,SASO certification.
We also have a factory in Vietnam, specialized in solar panels, annual output:1000MW Your satisfaction is our goal!
Payment terms
Payment Term |
T/T | EXW |
30% T/T in advance, the balance before shipment |
FOB | |||
CFR(C&F) | 30% T/T in advance, the balance before shipment or against copy of B/L. | ||
CIF | |||
L/C | L/C amount above USD50,000, we can accept L/C at sight | ||
West Union | Amount lower than USD5000
| ||
Delivery Time | 15~20days after receiving down payment | ||
We welcome use Trade Assurance order, you'll enjoy:
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
Packaging & Shipping
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q3. Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4. Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
