Sealed Type and Solar System Usage 24V 200AH battery
Product Description
Model | 6-CNJ-100 | |
Nominal voltage | 12V | |
Nominal capacity(10hr) | 100.0AH | |
Dimensions | Length 405±3mm Width 173±3mm Container Height 231±3mm | |
Approx. weight | Approx.30.0 kg | |
Container material | ABS | |
Rated capacity 25℃/77℉ | 111.0AH/20 hour rate (5.55A) 91.5 AH/5 hour rate (18.3A) 66.5AH/1 hour rate (66.5A) | |
Internal resistance | Approx 5.3mΩ | |
Operating temp. range | Discharge : -15- 50℃ (5 -122℉) Charge : 0 -40℃ (32- 104℉) Storage : -15- 40℃ (5- 104℉) | |
Nominal Operating temp. range | 25 ± 3℃ (77 ± 5℉) | |
Charge (constant voltage )25℃(77℉) | Float | Initial Charging Current less than 25.0A. Voltage 13.6V-13.8V |
Cycle | Initial Charging Current less than 25.0A. Voltage 14.4V-14.9V | |
Capacity affected by temperature | 40℃ (104℉) 102% 25℃ ( 77℉) 100% 0℃ ( 32℉) 85% -15℃ ( 32℉) 65% | |
Self-discharge Capacity 25 ℃(77℉) | Remaining capacity after 3 months of storage :90% Remaining capacity after 6 months of storage:80% Remaining capacity after 12 months of storage:62% | |
More detailed infomation or latest catalogue,send enquiry now.
Related Products
Battery Applications
Company introduction
Yangzhou Zhongming Technology Co.,ltd is a professional manufacture of new energy products,
Mainly including solar street lights,solar battery,solar panel,solar power system,etc.
We insist on quality first,customer first.
Our products are qualified with CE,ROHS,IEC,FCC,TUV,CCC,ISO,SONCAP,SASO certification.
We also have a factory in Vietnam, specialized in solar panels, annual output:1000MW Your satisfaction is our goal!
