| Product | Subsoil Rotary Combined Implement | ||||
| Model | DR-200W | DR-250W | DR-300W | DR-350W | DR-420W |
| Matched Power(hp) | 110~135 | 125~150 | 140~165 | 180~260 | 210~260 |
| Dimension (cm) | 295×293×141 | 290×333×141 | 305×395×155 | 312×440×150 | 293×503×152 |
| Working Width(cm) | 200 | 250 | 300 | 350 | 420 |
| Weight(kg) | 1680 | 2045 | 2390 | 2650 | 2900 |
| No. of shovel(pcs) | 4 | 4/6 | 6 | 6 | 8 |
| Space of Shovels (cm) | 55 | 62/42 | 52 | 55/70 | 55/60 |
| Depth S Shovel (cm) | 25--35 | ||||
| Depth M Shovel (cm) | 35--40 | ||||
| Depth L Shovels (cm) | 40--50 | ||||
| Depth of Rotary (cm) | 8-18 | ||||

1.Our subsoil Rotary combined implement is used for loosening and also the rotary tilling for the seedbed preparing.
2.It can complete deep subsoiling, cultivating, breaking of cold and suppress.
3.The Mn25B5 steel shovel with good wear resistance and the tips can be replaced.
4.Different shovel (small, medium and large) is optional to match your tractor.
5.With protection devices, and different Style pack roller for your optional.
6.Our machine is mounted to the tractor via three-point linkage.
