2SIM 3G GSM / UHF modem 4GNSS ModemOS with Wi Fi automatic switching
- Category: >>>
- Supplier: LLC Orient Systems
Share on (62025533633):
Product Overview
Description
Product Description
2SIM 3G GSM modem with automatic switching between SIM cards, the built-in Rx/Tx 2W UHF modem
Automatic switching between SIM-cards depends on the combination of stability of the correction stream and power of GSM signal, unlike most modems. Therefore, ModemOS creates a reliable channel for correction information stream.
The built-in Rx/Tx 2W UHF modem with a frequency range of 410-470 MHz and support for the Trimtalk 450S and Transparent protocols allows you to use the ModemOS as a normal UHF modem.
Intelligent selection of the most reliable stream of corrections between GSM1, GSM2 and UHF - type of communication automatically switches depending on the presence or absence of UHF signal or GSM network.
Country of origin
• Russia
Detailed Images
Specification
Overview |
2SIM 3G |
Automatic switching between SIM cards |
Web interface |
TCP/IP and NTRIP-client support |
Built-in 2W UHF modem (optional) |
IP67 |
Communications | ||
Communication port | • 1 port DB15: - 1 RS232 baud rate up to 230400 bps - Power - Compatible with Satel interface/power cable | |
2W UHF modem (optionally) | - 410-470 MHz frequency range - 2W - TRIMTALK, TRANSEOT, TRIMMK3 - UHF antenna TNC (f) | |
Wi-Fi/3G module | • 2SIM GSM modem: - 2G/3G: 900/2100 MHz - GSM1 antenna TNC (f) - GSM2 antenna TNC (f) • TCP-IP and NTRIP-client | |
• Wi-Fi (APN) | ||
WebUI | ||
Physical | ||
Size(L×W×H) | 145 mm × 85 mm × 35 mm | |
Weight | 0.9 kg (1.0 kg with UHF) | |
Antenna | 4 x TNC (f) | |
Environmental | ||
Working temperature | -40℃ to +85℃ | |
Storage temperature | -40℃ to +85℃ | |
IP protection | IP67 | |
Electrical | ||
Input voltage | 7-28 VDC | |
Amperage | 4A | |
Packing & Delivery
Port | St. Peretburg |
Processing Time | 2 days |
MOQ | 1 piece |
