HUAF Item No.:ZD X ventilator rotary hammer switches for extractor fan

Product Overview

Description



 HUAF Item No.:ZD-X ventilator rotary hammer switches for extractor fan                                                   Item No.:ZD-X



Technical Parameter
Electrical Rating	1A~250V.AC.
Function	OFF, L-1, L-2, L-3, OFF
HZ	60/50
Load	Res/ Mot
Temp(C)	125°C
Pol/Thr	1/ M
PP/Circuit	A/--
Endur	10K
SPCOA	24-18AWG UL1015
Material:
Cover: PC                Flame rating: V-2 or V0             Temperature: 130°C              Grade: Dupont
Movable Contract: Copper
Terminals: Brass
Base: PC         Flame rating: V-2 or V0                      Temperature: 130°C            Grade: Dupont
Apply to:
Electric Wall fan, Exhaust fan extractor fan ,and other home appliances
