API 17J Flexible Composite Pipe RTP Pipe for Oil and Gas
- Category: >>>
- Supplier: Dongying Lake Petroleum Technology Co. Ltd.
Share on (62027829699):
Product Overview
Description
API 17J Flexible Composite Pipe RTP Pipe for Oil and Gas
Product Description
Flexible Composite Pipe is a kind of composite pipe developed inter- nationally in recent years, its main features are corrosion resistance/ high operation pressure endurance and keeping flexibility at the same time, it can be made into a reel form (continuous pipe), with a length from tens of meters to kilometers in one reel.
Structure | Function | Material Selection | Remarks |
Inner Tube | For fluid or gas transportation | PE80 or PE100 | May choose other high perfor- mance polymers such as PA, PVDF to meet the requirement. |
Reinforce-ment Layer
| Endure Internal Pressure | High strength fiber or steel | May choose various reinforcement material such as aramid fiber, poly- ester fiber, glass fiber, steel wire, steel cord or steel tape |
Outer Layer | Provide protection from outside | PE80 or PE100 | May choose other polymers such as PA, PVDF to meet the protection requirement |
Pipe Structure:
Pipe Type:
Steel-cord Reinforced Thermoplastic Pipe
Aramid-fiber-belt Reinforced Thermoplastic Pipe (RTP)
Plastic Steel-belt Reinforced Pipe (PSP)
Glass-fiber Reinforced Pipe (GRP)
Pipe Application:
Land Oil & Gas
Offshore Oil & Gas
Petrochemical Industry
Technical parameter
Pipe Specification:
Nominal ID | 2 inch | 3 inch | 4 inch | 5 inch | 6 inch | 8 inch |
Operation Pressure | 2.5-42Mpa | 2-32Mpa | 2-32Mpa | 1.6-16Mpa | 1-16Mpa | 1-16Mpa |
Operation Temperature | -40°C –130°C | |||||
Inner Tube | Polymers such as PE80, PE100, PA, PEX, PVDF etc. | |||||
Reinforcement | Reinforced material such as aramid fiber, polyester, glass fiber, steel wire, steel cord and steel tape etc. | |||||
Outer Layer | Polymers such as PE80,PE100, PA, PEX, PVDF etc. | |||||
Remarks: Flexible composite pipe products are designed, qualified, and manufactured in accordance with API SPEC 15S, API SPEC 17J or API SPEC 17K. Products can be specially designed according to client’s requirements. | ||||||
Any inquiries, freely contact me:
Skype: julia0402zcy Whatsapp: +86 18661596896 Wechat: juliazcy
Product Overviews
Quality Control
Company Information
Lake Petro company is a professional supplier of various oilfield equipment, including oil drilling and service equipment,oil production equipment,OCTG ,wellhead & downhole tools and spare parts with API certification. Following the principle of "quality first, science and technology innovated, people oriented", every Lake Petro person is sparing no effort to provide the customers with best products and services. Through efforts of Lake Petro staff, our products have already been exported to USA, South America, Africa, Middle East, Russia and some other countries (regions). With super quality, reasonable price and professional service, Lake Petro company has become VIP (assigned) supplier and built strategic partnership with some coutries' national petroleum companies.
FAQ
How can I place order?
A: You can contact us by email about your order details, or place order on line.
How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank), Western Union are the most usual ways we are using.
What’s the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.
