VanGaa High CRI 95/97 Optional 100W Professional Video Spot Film DMX LED Fresnel Light

Share on:

Price:$225.00 - $350.00
Price in USD:Details


Product Overview


The Manufacturer

STAGE AND THEATER LIGHTING: The VanGaa PB100W lighting fixture is equipped with a 8-inch Fresnel lens and powered by a 100W LED engine. It produces a white wide, soft-edged beam for stage and theatre use at 3200K.、
MANUALLY ADJUSTABLE ZOOM: The adjustable Knob are fitted to adjust beam angles between 8 and 50 degrees allowing for a broad stage-filling wash to generating a concentrated pool of light.
STANDARD DMX-512 CONTROL: Offers smooth 0-100% dimming through DMX protocol and includes a LCD display menu to easily select a DMX address as well as any of the fixtures’ operating options.
LONG-LASTING PROFESSIONAL DESIGN: Powered by a high-powered LED bulb low power draw as well as minimal excess heat and designed with a robust aluminum case for a lasting and durable lighting solution.
PRODUCT SPECIFICATIONS: 8-inch Fresnel lens, CRI 95, 4-button LCD menu, 3-pin DMX In/out, Wired Digital Communication Network, powerCON In/Out to daisy chain power, Multi-voltage operation: AC 100-240V, 50/60Hz, 17.91” x 10.43” x 11.49” / 455x265x292mm, 16.53 lbs / 7.5 kg.


Light source
1pc 100W COB LED Lamps
Color temperature
3200K/5600K optional
Beam angle
15-60° manual zoom
 under 45db
Ra≥95,OR Ra≥97
Fresnel lens
DMX channel
1CH/2CH    DMX-512
Related power
100W AC100-240 V, 50/60 Hz
Body dimension
17.91” x 10.43” x 11.49”
Net weight
7.5KG/16.53 lbs

VanGaa 100W PB100W led fresnel spot light for theater
Designed for various theater studio TV station lighting
Combining the benefits of modern LED light-sources with the features of a traditional stage lighting Fresnel fixture, the VanGaa PB100W offers the best of both worlds. Low power consumption, minimal excess heat and long lamp life are combined with a wide zoom range and barn doors to create a pair of truly versatile fixtures. Create soft-edged beams for highlighting or illuminating the stage..

A Professional Lighting Kit for TV Station

* 3-pin+5-pin DMX In/Out and powerCON In/Out
* 4-Button LCD Operational Menu
Color temperature
White Wide, Soft-Edged Beam for Stage and Theatre Use at 3200k/5600K
Beam Angle
Change the Beam Angle from 15 to 60 Degrees

VanGaa LED Studio Fresnel Light Series

Product Description

Main feature
The internal adopts full copper radiator large area, good heat dissipation, ensure the lifespan of the LED Lamps;
Through efficient optical lenses, with special heat dissipation design, make the light is downy, small stray light, no glare, eyes more comfortable;
Use the LED video projector scheme, the light energy saving 80%;
Because of almost no infrared radiation, it has greatly improve work environment.

Technical Specifications
Light Sources
* LED: 1pc 100W COB LED Lamps
* Lifespan: 500,000h
* Color: CW, WW optional

* Beam angle: 15-60degree
* Dimmer: 0-100% linear dimmer

Light Output
* Luminous flux: 3810
* Illuminance: 678 Lux (6m 15°)
* Optimal projection distance: 5-15m

* Control mode: DMX-512; Auto run
* DMX channel: 1CH, 2CH
* Display of control panel: LCD display + 4 buttons

Power Supply
* Related voltage: AC100V-240V, 50/60Hz
* Related power: 150W

* Body dimension: D455*W265*H292mm
* Net weight: 7.5kg
* Shell color: black
* Shell material: aluminium die casting

Working Environment
* Working temperature: -25-40℃
* Cooling: Radiator and Fan
* Protection rating: IP20

Standard Configuration Spare Part List
* Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)
* User manual: English version user manual

Optional Configuration Spare Parts List
* Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)
* Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Production Images

Product package:

Flight case(customized and optional)
Thick woodboard
Long hinge
Quality aluminum alloy
Best rubber wheels

Panel Light Series

Company Profile

About us
Guangzhou VanGaa lighting Co,Ltd , Founded in 2014,Located in Huadu district of Guangzhou City. Well trained staff, strict
quality control, and professional sales team, provide excellent before sale and after sale service.
* Manufacturer / Factory
* Accept OEM & ODM
* Qualified with CE, ROHS, FCC certificates
* One store service from product to your door
* Our goal : keep growing and expanding with clients


ISO certified factory, products strictly in compliance with CE, RoHS standards.



Q. Can i order light with my own design and Logo?
A:Definitely yes,we offer custom services according to your specific requirements

Q.what format do you need for logo?

Q. Are there any other related products?
A:Yes,we can purchase Filght case,Lamp hang,Constant force hinge,Slide way,Tripod,Safety rope

Q. Can I have a sample order for led stage light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q. How to proceed an order for led light?
A: 1 let us know your requirements or application.
2 We quote according to your requirements or our suggestions.
3 customer confirms the samples and places deposit for formal order.
4 We arrange the production.

Q. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.

Q. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available

Q. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q: Do you offer guarantee for the products?
A: Yes, we usual offer 1 years warranty to our products( Of course you can opt for a lifetime warranty).After the warranty period, we can continue to provide after-sales service of products and replacement of spare parts
