China supplier nema 43 High power 3000RPM Permanent Magnet BLDC 48v 1000w brushless dc motor for Electric Bicycle Usage

Product Overview

Description

China supplier nema43 High power 1KW 3000RPM  Permanent Magnet BLDC  48V brushless dc motor for Electric Bicycle Usage



Note: the motor with magnetic ,so magnetic inspection fee will be incurred during transportation. Please contact shop assistant to supplement it.large quantities can dispense with it



KeyWords	Brushless DC Motor
Number of poles	8
Rated Voltage	48V
No Load Speed	4000±10%
No load current (Max)	2.5A
Rated Speed	3000±10%
Rated Torque	3.2NM
Rated power	1KW
Rated Current (Max)	28A
Peak Torque	9.6NM
Torque constant	0.12NM/A
Back EMF	8.4V/krpm
Rotor inertia	730kg.mm2
Body length	110mm
Mass	4.5Kg
