JYP300VF Metal Lathe with Milling Head

Share on (62030913679):


Price:$3,000.00

Quantity:


Product Overview

Description


WELCOME

MULTI USE LATHE FEATURES:
The SKF bearing is used for the spindle, which is more accurate than other machines, with smaller sound and longer life.
It is very convenient to disassemble and use the C-type spindle. After only loosening the three nuts, the chuck can be replaced by rotating the locking disc.
Full metal gear, low noise, CNC machine tool shifting solution. Adopt 1.5KW variable frequency motor.

\t
MODEL
\t
JYP300VF
\t
Distance between centers
\t
700 mm
\t
Swing over bed
\t
300 mm
\t
Swing over cross slide
\t
175 mm
\t
Width of bed
\t
180 mm
\t
Taper of spindle bore
\t
MT5
\t
Spindle bore
\t
38 mm
\t
Number of spindle speeds
\t
Variable
\t
Range of spindle speeds
\t
30-3000 rpm
\t
Range of longitudinal feeds
\t
0.07-0.65 mm/r
\t
Range of inch threads
\t
8-56 T.P.I
\t
Range of metric threads
\t
0.2-3.5 mm
\t
Top slide travel
\t
80 mm
\t
Cross slide travel
\t
140 mm
\t
Tailstock quill travel
\t
94 mm
\t
Taper of tailstock quill
\t
MT3
\t
Motor
\t
1.5 kw
\t
Mill & drill
\t
Taper of spindle bore
\t
MT2
\t
Max drilling capacity
\t
20mm
\t
End milling capacity
\t
16mm
\t
Face milling capacity
\t
63mm
\t
The width of T Slot
\t
10mm
\t
Spindle speed
\t
50-2250 rpm
\t
Motor
\t
750W
\t
Packing size
\t
1400x750x1010 mm
\t
Net weight
\t
300/340 kg
