High efficiency wood pellet separator linear sieve coffee bean square vibrating sieve

Product Overview

Description

Square vibrating sieve features:
Straight-line series vibrating sieve machine use centrifugal force generated on the vibration power machine to obtain exciting force.The exciting force makes the sieve body and the materials to move repeatedly up and down;after selection by two layers of screen,the materials are divided into threelevels according to the diameter of the sieve so as to reach the ideal goal.

1.The linear vibrating screen has fine and durable design,easy to be operated.
2.Convenient and rapid net changing and cleaning.
3.All contact parts of this kind of linear vibrating screen are made of stainless steel to ensure the purity.
4.Less malfunction,easy maintenance and convenient repairing.
5.Except standard configuration,diameter of sieve holes may be tailored according to customers' requirements.

Technical parameters:

Model	Power (kw)	Area of  Mesh (mm)	Diameter of Sieving Hole(mm)	Layer of Meshes	Dimension(mm)
TZS-100	0.25	980x460	2-8	2	1500x720x880
TZS-130	0.25	960x440	2-8	2	1300x550x700
TZS-140	0.25	960x440	2-8	2	1400x650x1180
