Professional outdoor sfp fiber layer 3 ethernet switch made in China





Overview





HiOSO FOWAY7500-16FS is a 16 port 10G fiber switch, provide 16 1000M/10G SFP+ fiber ports,support the SFP/SFP+hot plug, and supports to work with other fiber switches, fiber converters and other devices with fiber ports.It supports WEB management and SNMP management optional , Support super network high definition video frequency transmission ability ,Streamlined network structure, support dual power supply hot backup, applies to security system, electric system, traffic system center server room ,district, schools, government, shopping malls, Internet bar etc.





Character


1.Support 16 1000M /10G SFP+ fiber port


2.Support the default 1000M SFP and 10G SFP+ hot plug


3.Managed version Support WEB ,and SNMP management (optional):VLAN,STP/RSTP,Trunk port aggregation, IGMP,port Mirroring,port isolation,broadcast control,loop detection,QinQ, etc


4.Support DHCP,PPPoE,ACL,LLDP


5.Support 16K MAC learning, 16Mbit storage and forward cache space,320G back plane bandwidth,9KByte Large frame


6.All optic ports, strengthen the an-interference ability


7.Support the AC dual redundant power supply hot backup and DC12V/5A spare battery power


8.Standard 1U rack ,internal double cooling fan,better for heat dissipation,work stable .


 Foway7500-16-02 (1).jpgFoway7500-16-02 (2).jpgFoway7500-16-04.jpg





Technical Specification





































































Parameter



Specification



Standard



IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree Protocol,IEE802.1w Rapid STP,IEE802.1s Multiples STP,IEE802.1q Vlan,IEE802.1q Qos,IEE802.3ad Trunk,IEE802.3X Flow Control



Wavelength



SFP:850nm/1310nm/1490nm/1550nm



Distance



100M SFP   Multi-mode: 2km (fiber size 62.5/125μm or 50/125μm)


            Single-mode: 20/40/60/80/100/120Km


            Single-fiber single-mode: 25/40/60/80/100/120Km


1000M SFP  Multi-mode: 220m (fiber size 62.5/125μm)/550m(fiber size 50/125


             μm)


            Single-mode: 10/20/40/60/80/100/120Km


            Single-fiber single-mode:10/20/40/60/80/100/120Km
CAT5: 100m



Port



16 10G+ SFP fiber ports: 10G SFP+


1 console management port


1 100M CPU  RJ45 management port


1 USB console port



MAC



16K



Buffer memory space



16Mbit



Bit error rate



<1/1000000000



MTBF



100000 hours



Power



AC 110-230V



Power consumption



23W



Working


temperature



-10~60℃



Storage temperature



-40~80℃



Humidity



5%~90% non-condensing



Dimension



44mm (H)×440mm(W)×210mm (D)
