Bulldozer SD13 Engine Shanghai SC8D143G2B1
- Category: >>>
- Supplier: Shanghai Vostosun Industrial Co. Ltd.
Share on (62033942556):
Product Overview
Description
Product Feature and Advantages:
Bulldozer SD13
Operating Weight: 13.7 t
Power: 95.5 kW / 130 HP
Engine Shangchai SC8D143G2B1
The Sd13 Gets Mid-Range Volume Jobs Done In Record Time. A Smaller Version Of Our Best-Selling Sd16 Line, The Sd13 Delivers All The Durability And Reliability Of Its Larger Cousin Series. With A High-Power, High-Efficiency, Turbocharged Engine Featuring A Large-Torque Reserve Coefficient, The 130 Hp Sd13 Is Ready For Work.
Its Extended Track Ensures Low Ground Pressure, High Reliability And Strong Traction While The Comfortable Wide Visibility Hexahedron Cab And Integrated Dashboard Design Help Keep Operator Productivity At Peak Levels.
Engine Model: Shangchai Sc8d143g2b1
Rated Power: 95.5 Kw/1900 Rpm
Operating Weight: 13.7 T
Technical Specification:
|
Engine |
Model & Type |
Shangchai Sc8d143g2b1; Water-Cooled, In-Line, 4-Cycle, Direct Injection And Turbocharged |
||
|
Power |
Rated Power |
95.5 Kw |
||
|
Number Of Cylinders |
6-114 X 135 Mm (Bore X Stroke) |
|||
|
Piston Displacement |
8.27 L |
|||
|
Min. Fuel Consumption |
228 G/Kw-H |
|||
|
Maximum Torque |
674 N-M@1300 Rpm |
|||
|
Torque Converter |
3-Element, 1 Stage, 1 Phase |
|||
|
Transmission |
Forced Connected, Planetary Gear, Power Shift |
|||
|
Transmission System |
Main Drive |
Spiral Bevel Gear, Splash Lubrication |
||
|
Steering Clutch |
Wet, Multi-Disc, Spring Loaded, Hydraulic Helping Operation, Mechanical Separating, Linking Steering Brake |
|||
|
Steering Brake |
Wet, Floating, Band Type Foot Stepping Brake With Hydraulic Helping |
|||
|
Final Drive |
2-Stage Speed Reduction Of Spur Gear, Splash Lubrication |
|||
|
Torque Converter |
3-Element, 1 Stage, 1 Phase |
|||
|
Travel Speed |
Gear |
1st |
2nd |
3rd |
|
Forward |
0-3.2 Km/H |
0-5.9 Km/H |
0-9.8 Km/H |
|
|
Reverse |
0-3.9 Km/H |
0-7.1 Km/H |
0-11.9 Km/H |
|
|
Undercarriage System |
Type |
Swing Type Of Sprayed Beam, Suspended Structure Of Equalizer |
||
|
Carrier Rollers |
2 Each Side |
|||
|
Track Rollers |
6 Each Side |
|||
|
Track Type |
Single Grouser, Dry Type |
|||
|
Width Of Track Shoes |
460 Mm |
|||
|
Pitch |
190 Mm |
|||
|
Hydraulic System |
Maximum Pressure |
14 Mpa |
||
|
Pump Type |
Gear Pump |
|||
|
Discharge |
180 L/Min |
|||
|
Bore Of Working Cylinder X No. |
90 Mm X 2 |
|||
|
Blade Type |
Straight-Tilt |
Angle |
||
|
Blade |
Dozing Capacity |
3.7 M3 |
3.4 M3 |
|
|
Blade Width |
3185 Mm |
3745mm |
||
|
Blade Height |
1090 Mm |
915 Mm |
||
|
Maximum Drop Below Ground |
590 Mm |
590 Mm |
||
|
Maximum Tilt Adjustment |
400 Mm |
400 Mm |
||
|
Ripper(Optional) |
Maximum Digging Depth Of 3-Shank Ripper |
467 Mm |
||
|
Maximum Lift Above Ground |
559 Mm |
|||
|
Weight Of 3-Shank Ripper |
1421 Kg |
|||
