PIR Motion Sensor Detector With Rechargeable Battery 433MHz 1527 Code

Product Overview

Description

Wireless Intelligent PIR Motion Sensor Alarm Detector With Li-ion Battery



GS-WP1 is a professional new housing Passive Infrared Motion Detector (PIR) that powered by 3.6V Lithium rechargeable battery, the PIR with internal antenna design, hidden Power On/OFF switch. It built-in with learn button make users easy to program it into wireless alarm system.



When motion is detected, the unit emits a signal to the alarm main unit to set off the alarm. The wireless transmission range is 100 meters in open space and with low power indication and send wireless signal to alarm systems.



Technical Specification:



• Power supply: 3.7V rechargeable Lithium battery
• Static Current: less than 12uA
• Alarm current: less than 15uA
• Infrared sensor: Dual element, high sensitivity, low noise
• Mounting Method: Wall or corner mounted with bracket
• Radio frequency: 433MHz/868MHz
• Radio distance: 100m (open area)
• Alarm indicator: Red/Blue LED
• Detection angle: 9-12m, 110 degree
• Installation height: About 2m
• Environment humidity: 95% RH (no congelation)
• Pulse count: No
• Temperature: -10°C~50°C(14°F~122°F)
