Best Selling Market: Central, North & East Europe, North Europe, North America.
Ambient Temp of Using: Minus 25C, highest 60C hot Water Output and cooling.
Certification: ISO9001, CE, erP Energy Label, ROHS.
Use *Mitsubishi* dual-rotor Compressor for Dc Inverter Air Source Heat Pump.
DC inverter model, suitable for 220/380V ~ 50HZ power supply.
Parameters of Nulite NEW ENERGY DC inverter heating cooling Hot water pump
Model
BKDX30-95I/1/S
BKDX50-200I/1/S
BKDX60-220I/1/S
Power source
220V~50HZ
220V~50HZ
220V/380V~50HZ
Heating capacity
2.6KW~9.5KW
4.5KW~20KW
5.6KW~22KW
Rated input power
1KW~3KW
2KW~5.5KW
2.5KW~6.6KW
Testing condition: DB temperature 20℃, WB temperature 15℃, water output temperature 45℃.
Heating capacity
2.6KW~8.8KW
4.5KW~14KW
5.2KW~16.8KW
Rated input power
1KW~3KW
2KW~5.5KW
2.5KW~6.6KW
Testing condition: DB temperature 7℃, WB temperature 6℃, water output temperature 45℃.
Cooling capacity
2.5KW~7KW
4.5KW~11KW
5.6KW~13.5KW
Rated input power
1KW~3KW
2KW~5.5KW
2.5KW~6.6KW
Testing condition: DB temperature 35℃, WB temperature 24℃, water output temperature 7℃.
Rated water flow
1.8m³/h
3.1m³/h
3.8m³/h
Noise
Less than 56dB(A)
Less than 58dB(A)
Less than 58dB(A)
Pipe size
G1''
G1''
G1''
Unit weight
100KG
140KG
145KG
Unit size
1105*452*904MM
1214*539*1256MM
1214*539*1256MM
Refrigerant
R410A
Detailed Images
Tips for choosing heat pump with right heating capacity according to heating space
BKDX30-95I/1/S (220V~50HZ/10KW): suitable for 60~100sqm, about 3M height.
BKDX50-200I/1/S(220V~50HZ/20KW): suitable for 160~200sqm, about 3M height.
BKDX60-220I/1/S (220V/380V~50HZ/22KW): suitable for 160~220sqm, about 3M height.
Installation diagram and available parts.
Pls note that the unit is only include heat pump and liner controller, other parts such as water tank, water pump,
fan coil units do not include.
Purchasable accessories: water tank, water pump, fan coil units.
Details of BKDX DC inverter heating cooling DHW heat pump
Packaging & Shipping
Packing Details : stable plywood box package,0.68 CBM for10KW, 1.15CBM for 20/22KW,1.96CBM for 30KW dc inverter heat pump Delivery Details : 1-25 working days after receiving payment by T/T, or alibaba trade assurance payment Dealing Details: EXW factory, FOB Guangzhou/Shenzhen Port, CIF to destination Port, DDP Door to Door Service provided.
Related products
Company Information
Nulite New Energy Technology Co.,Ltd in Guangdong, China.
The official heat pump supplier of 18th Asian Games, owning three main modern factory covering 580,000 square meters, 1,200,000 units supply ability and over 1,500 employ.
Currently there are 8 kinds of high efficient heat pump available: 1. Apartment/Villa Inverter Heating/Cooling Series (3-38KW, 30-350m2) 2. -25°C EVI Heating Series (9-210KW) 3. Sanitary All in One Series (80-320L) 4. Swim Pool Series (3-150KW) 5. Commercial Central HVAC Series (10-180KW) 6. Geothermal Series (3-150KW) 7. Fan Coil Unit & Water Tank (50L-10T) 8. Mini Hot Water Geyser Series (3-10KW)
Our Services
Our customers and their feedback
For hige quality and performance air source heat pump, call me.
FAQ
FAQ
Q1. What is your terms of packing? A: Generally, we pack our goods in neutral cartons and polywood. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time? A: Generally, it will take 30 to 40 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples? A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy? A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship? A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
