45Mm 20N.M Standard Dolat Tubular Motor For Roller Shutter And Roller Door

Product Overview

Description

       1. How to choose a suitable motor?
           The formula is :N.m=Reel pipe Radius(mm)*loading weight(kg)/100.

           For example, if the loading weight is 50kg ,and the reel pipe radius is

           30mm,please figure out the torque of the motor. N.m=30*50kg/100=15N.m.

       2.How about the weight can the motor load?
          The formula is :Loading weight(kg)=N.m*100/ Reel pipe Radius(mm).

          For example: the torque of the motor is 15N.m,the Reel pipe Radius is 30mm

          please figure out the the loading weight.Loading weight(kg)=15N.m*100/ 30 Reel

          pipe Radius(mm)=50kg.

       3.What's your MOQ?
          1 pieces.If you order more,there will be a discount.

       4.Are you manufacturer or trading company?
          We are manufacturer for 16 years experience.

       5.Can I customize the packing and motor's color?
          Yes,we can produce the packing according to your design.



       6.My order quantity is small, can you provide?
          We support sample/small/big/full order, and no matter how many quantity you

          want, we will always provide you the fastest and professional service right away.

       7: Can you accept OEM service?
           Yes, sure and welcome

       8: What is the lead time?
           Sample is 7days, small trial or full order is usually 7-15days.



       9: What kind of payment do you accept?

            Payment welcome T/T, L/C,Alibaba Trade Assurance (more welcomed)



      10: Can you provide free sample?

            Can be negotiation,According to the true order.
