all wheel drive all terrain ev vehicle for rescue, Mountain, swamp, river
- Category: >>>
- Supplier: Main New Energy Co. Ltd.
Share on (62039328077):
Product Overview
Description
all wheel drive all terrain vehicle for rescue, Mountain, swamp, river
Product Display
Product Details
| Dimension | 3160×1720×1150mm | |
| Wheel Base | 670×670×670mm | |
| Track | 1420mm | |
| Minimum Ground Clearance | 180mm | |
| Complete Vehicle Kerb Mass | 750kg | |
| Rated Load | On Land:500kg(6 People) | |
| On Water:300kg(4 People) | ||
| Start Mode | Key | |
| Ignition Mode | EFI | |
| Battery Specification | 12V/60Ah | |
| Drive Mode | On Land: All-wheel Drive | |
| On Water: All-wheel Drive or Outboard Drive | ||
| Top Speed | On Land:45km/h | |
| On Water: 5km/h(Tyre Stroke)or 12km/h(15HP Outboard) | ||
| Minimum Turning Radius | 0.71m | |
| Maximum Climbing Angle | 32 º | |
| Approach Angle | 54 º | |
| Departure Angle | 57 º | |
| Brake Mode | Caliper Hydraulic Brake | |
| Tyre Specification | 25×12(11.5)-9NHS | |
| Tyre Pressure | 5-7psi (34.5-48.3kPa) With Track: 3-5psi(20.7-34.5kPa) | |
| Transmission Mode | Belt and Chain Transmission | |
| Engine Model | SQR372 | |
| Engine Type | Vertical 3-Cylinder, Water-cooling, 4-Stroke, Inline DOHC | |
| Oil-supply Mode | MPI | |
| Cylinder Diameter ×Stroke | 3-72×66.5mm | |
| Displacement | 812ml | |
| Compression Ratio | 9.5:1 | |
| Rated Power and Turning Speed | 39kW(6000r/min) | |
