3G/4G/WIFI/GPS 2019 seks video animation led P5 Taxi top display outdoor
- Category: >>>
- Supplier: Shenzhen Signic Electronics Co. Ltd.
Share on (62042412382):
Product Overview
Description
3G/4G/WIFI/GPS 2019 seks video animation led display outdoor
1.Key Features:
1.High Resolution 2.5,3,3.33,5 mm pixel Spacing
2.Intensity >=5000 nit
3.Intelligent Power Supply Management
4.Quick installation and maintenance
5.Multiple control Options
6.Made of high quality LEDs
7.Lower Power Consumption
2.Intensity >=5000 nit
3.Intelligent Power Supply Management
4.Quick installation and maintenance
5.Multiple control Options
6.Made of high quality LEDs
7.Lower Power Consumption
![%~B$77ZCD_7]]LFJPI]_5Z5.jpg](http://sc01.alicdn.com/kf/HTB1M.XmKMHqK1RjSZFgq6y7JXXao/225140011/HTB1M.XmKMHqK1RjSZFgq6y7JXXao.jpg)
2.Specifications:
3.Product desctription:
| Model Type: | P2.5 | P3.33 | P3 | P5 | ||
| Pixel Pitch | 2.5 mm | 3.33mm | 3mm | 5mm | ||
| LED Type | SMD 2121 | SMD1921 | SMD1921 | SMD 2727 | ||
| Pixel Density | 160,000 dot/ m2 | 90,000 dot/ m2 | 111,111 dot/ m2 | 40000 dot/ m2 | ||
| Module Size | 160*160mm | 320*160mm | 192*96mm | 160*160mm | ||
| Frame Size | 1100mm( L) x 410mm(H) X W:164mm(bottom)/ 99mm (top) | 1100mm( L) x 410mm(H) X W:164mm(bottom)/ 99mm (top) | 820mm( L) x 390mm(H) X W:170mm(bottom)/ 99mm (top) | 1100mm( L) x 410mm(H) X W:164mm(bottom)/ 99mm (top) | ||
| Screen Size | 960mm*320mm | 960mm*320mm | 768mm*288mm | 960mm*320mm | ||
| Screen Resolution | 384*128 dot | 384*128 dot | 256*96 dots | 192*64 dot | ||
| Brightness | >=5000 nit | >=4500 nit | >=3500 nit | >=5500 nit | ||
| Contrast | >8000:1 | |||||
| Scan Mode | 1/32 scan | 1/24 scan | 1/32 scan | 1/8 scan | ||
| Power Supply Input | DC9--24V | |||||
| Max Consumption | 420w | 420w | 270w | 450w | ||
| Average Consumption | 130w | 120w | 90w | 150w | ||
| Optimal Viewing Distance | 1--20M | 3--20M | 3--20M | 5--50M | ||
| Driving ICs: | ICN2038 | |||||
| MTBF | 10,000 Hours | |||||
| Frame Frequency | 60-85HZ | |||||
| Fresh Frequency | >1920HZ | |||||
| Temperature Operating | -40°~+70° | |||||
| Working Humidity | 10%-90%RH | |||||
| Screen Weight: | 24 kg | 23 kg | 15kg | 23kg | ||
| Gross Weight: | 31 kg | 28 kg | 22Kg | 30kg | ||
3.Product desctription:
Muiti-Connection Mode Group Control
4.Package
5.Company information
6.Company Certificate
7.Workshop
8.Exihibition
